1222 / 1410
1222
Prices in EURO - VAT not included
1222
HIGH EFFICIENCY MACHINE TAPS
13
9082E
new
BSP
HSS-E
Orig. Hartner - Art. 80754
In HSS-E steel, particularly treated for superior performance and long life. Ground and polished
after hardening. Cutting geometry optimized for maximum chip evacuation.
Reduced shank, short chamfer for through and blind holes. Thread: cylindrical gas G - BSP - DIN
5156. Right-hand use. With nitrided surface. For all types of cast iron and its alloys, non-ferrous
short chipping metals and aluminum alloys with silicon (> 6%).
Ø
inch
1/16 1/8
1/4
3/8
1/2
5/8
3/4
7/8
Threads per inch
Nr
28
28
19
19
14
14
14
14
Overall length
mm 90
90
100 100 125 125 140 150
Thread length
mm 18
18
20
22
25
25
28
28
Shank Ø
mm 6
7
11
12
16
18
20
22
Shank square
mm 4,9
5,5
9
9
12 14,5 16
18
9082E
Each 79,60 50,80 70,10 89,20 125,00 156,00 198,00 286,00
Ø
inch
1
1.1/8 1.1/4 1.3/8 1.1/2 1.3/4
2
Threads per inch
Nr
11
11
11
11
11
11
11
Overall length
mm 160 170 170 180 190 190 220
Thread length
mm 30
30
30
32
32
40
40
Shank Ø
mm 25
28
32
36
36
40
45
Shank square
mm 20
22
24
29
29
32
35
9082E
Each 261,00 464,00 537,00 671,00 700,00 949,00 1.100,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9084A
new
M
HSS-E
TIN
Orig. Hartner - Art. 80900
FORMING TAPS with the coolant ejection channels for maximum performance. Short chamfer, no
chip production, for through and blind holes. TIN-coated. For machining materials with good cold
deformation characteristics and at least 10% elongation, for example: non-alloy steel up to 1000
N / mm², steel resistant to oxidation, acids and moisture, aluminum and its long chipping alloys.
Reinforced shank (from 12mm, reduced shank), for through and blind holes.
Thread: Metric - Coarse Pitch M - DIN 13 (DIN 371/376). Tolerance 6HX. Right-hand use.
Ø
mm
3
3,5
4
5
6
8
10
Pitch
mm 0,5
0,6
0,7
0,8
1
1,25
1,5
Overall length
mm 56
56
63
70
80
90
100
Thread length
mm 10
12
12
14
16
17
20
Shank Ø
mm 3,5
4
4,5
6
6
8
10
Shank square
mm 2,7
3
3,4
4,9
4,9
6,2
8
9084A
Each 52,80 60,40 54,70 56,60 61,40 75,80 99,70
Ø
mm
12
14
16
18
20
22
24
Pitch
mm 1,75
2
2
2,5
2,5
2,5
3
Overall length
mm 110
110
110
125
140
140
160
Thread length
mm 24
26
26
30
32
27
30
Shank Ø
mm 9
11
12
14
16
18
18
Shank square
mm 7
9
9
11
12
14,5
14,5
9084A
Each 116,00 177,00 185,00 288,00 305,00 300,00 269,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9084B
new
MF
HSS-E
TIN
Orig. Hartner - Art. 80901
Product description as Art. 9084A
Reduced shank, for through and blind holes. Thread: Metric - Fine pitch MF - DIN 13 (DIN 374).
Tolerance 6HX. Right-hand use.
Ø
mm
6
8
8
10
10
12
12
Pitch
mm
0,75
0,75
1
1
1,25
1
1,25
Overall length
mm 80
80
90
90
100
100
100
Thread length
mm 13
14
17
17
20
20
20
Shank Ø
mm 4,5
6
6
7
7
9
9
Shank square
mm 3,4
4,9
4,9
5,5
5,5
7
7
9084B
Each 130,00 141,00 113,00 116,00 150,00 145,00 154,00
Ø
mm
12
14
14
16
16
18
18
Pitch
mm
1,5
1
1,5
1
1,5
1
1,5
Overall length
mm 100
100
100
100
100
110
110
Thread length
mm 20
20
20
22
22
25
25
Shank Ø
mm 9
11
11
12
12
14
14
Shank square
mm 7
9
9
9
9
11
11
9084B
Each 149,00 192,00 185,00 248,00 209,00 288,00 255,00
Ø
mm
20
20
22
24
Pitch
mm
1
1,5
1,5
1,5
Overall length
mm 125
125
125
140
Thread length
mm 25
25
25
28
Shank Ø
mm 16
16
18
18
Shank square
mm 12
12
14,5
14,5
9084B
Each 336,00 290,00 372,00 392,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
