1223 / 1410
1223
Prices in EURO - VAT not included
1223
HIGH EFFICIENCY MACHINE TAPS
13
9084E
new
UNC
HSS-E
TIN
Orig. Hartner - Art. 80902
Product description as Art. 9084A
Reinforced shank (from 7/16 inches, reduced shank), for through and blind holes. Thread:
American - UNF pitch - ANSI-B1.1 (DIN 371/376). 2BX tolerance. Right-hand use.
Thread UNC
Nr. 4 Nr. 5 Nr. 6 Nr. 8 Nr. 10 Nr. 12 1/4
Threads per inch
Nr
40
40
32
32
24
24
20
Overall length
mm 56
56
56
63
70
80
80
Thread length
mm 11
11
12
13
14
16
16
Shank Ø
mm 3,5
3,5
4
4,5
6
6
7
Shank square
mm 2,7
2,7
3
3,4
4,9
4,9
5,5
9084E
Each 62,30 58,50 67,10 75,80 105,00 108,00 94,90
Thread UNC
5/16
3/8
7/16
1/2
9/16
5/8
3/4
Threads per inch
Nr
18
16
14
13
12
11
10
Overall length
mm 90
100
100
110
110
110
125
Thread length
mm 18
20
22
25
30
30
33
Shank Ø
mm 8
10
8
9
11
12
14
Shank square
mm 6,2
8
6,2
7
9
9
11
9084E
Each 118,00 135,00 167,00 168,00 269,00 242,00 351,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9084F
new
UNF
HSS-E
TIN
Orig. Hartner - Art. 80903
Product description as Art. 9084A
Reinforced shank (from 7/16 inches, reduced shank), for through and blind holes. Thread:
American - UNF pitch - ANSI-B1.1 (DIN 371/376). 2BX tolerance. Right-hand use.
Thread UNF
Nr. 4 Nr. 5 Nr. 6 Nr. 8 Nr. 10 Nr. 12 1/4
Threads per inch
Nr
48
44
40
36
32
28
28
Overall length
mm 56
56
56
63
70
80
80
Thread length
mm 10
10
11
12
14
16
16
Shank Ø
mm 3,5
3,5
4
4,5
6
6
7
Shank square
mm 2,7
2,7
3
3,4
4,9
4,9
5,5
9084F
Each 67,10 62,30 69,10 78,60 106,00 122,00 125,00
Thread UNF
5/16
3/8
7/16
1/2
9/16
5/8
3/4
Threads per inch
Nr
24
24
20
20
18
18
16
Overall length
mm 90
90
100
100
100
100
110
Thread length
mm 18
18
22
20
22
22
25
Shank Ø
mm 8
10
8
9
11
12
14
Shank square
mm 6,2
8
6,2
7
9
9
11
9084F
Each 135,00 135,00 168,00 192,00 244,00 259,00 307,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9084L
new
BSP
HSS-E
TIN
Orig. Hartner - Art. 80904
Product description as Art. 9084A
Reduced shank, for through and blind holes. Thread: cylindrical gas G - BSP - DIN 2189. Right-
hand use.
Ø
inch
1/16
1/8
1/4
3/8
1/2
3/4
Threads per inch
Nr
28
28
19
19
14
14
Overall length
mm 90
90
100
100
125
140
Thread length
mm 18
18
20
22
25
28
Shank Ø
mm 6
7
11
12
16
20
Shank square
mm 4,9
5,5
9
9
12
16
9084L
Each 107,00 143,00 176,00 246,00 319,00 338,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
MACHINE TAPS WITH DRILL
9088
M
HSS-E
Orig. Völkel - Art. 370
Tap with drill for quick drilling and tapping in one operation. In HSS-E steel. For through holes.
Right-hand use. M coarse metric thread, according to DIN 13. Normal chamfer.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
71
80
95
106
115
Tip Ø
mm 2,5
3,3
4,2
5
6,8
8,5
10,2
Shank Ø
mm 3
4
5
6
8
10
12
9088
Each 22,10 22,10 22,10 24,40 28,10 30,70 36,10
The material thickness must not exceed the size of 2 times the diameter (2 x D).
