1228 / 1410
1228
Prices in EURO - VAT not included
1228
HAND TAPS
13
9103G
LEFT USAGE
M
HSSG
Orig. Völkel - Art. 270
Product description as Art. 9100G
LEFT-HAND USE.
ISO METRIC THREAD – According to DIN 13 (DIN 352).
M Coarse Metric – Tolerance ISO 2/6H. 3Pcs set.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0.5
0.7
0.8
1
1.25
1.5
1.75
Overall length
mm 40
45
50
50
56
70
75
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3.5
4.5
6
6
6
7
9
Shank square
mm 2.7
3.4
4.9
4.9
4.9
5.5
7
9103G
Per series 15,90 15,90 18,40 19,30 20,60 26,50 36,40
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2.5
2.5
2.5
3
Overall length
mm 80
80
95
95
100
110
Thread length
mm 30
32
40
40
40
50
Shank Ø
mm 11
12
14
16
18
18
Shank square
mm 9
9
11
12
14.5
14.5
9103G
Per series 43,20 52,20 68,80 76,90 94,10 117,00
vuoto
HANDTAPS
9105G
9107G
MF
HSSG
Orig. Völkel
Product description as Art. 9100G
RIGHT-HAND USE.
ISO FINE METRIC THREAD – According to DIN 13 (DIN 2181.
MF Fine Metric – Tolerance ISO 2/6H. 2Pcs set.
Ø
mm
3
3.5
4
4
5
6
6
7
8
8
8
9
10
10
Pitch
mm
0.35 0.35 0.35 0.5
0.5
0.5 0.75 0.75 0.5 0.75
1
1
0.5 0.75
Overall length
mm 40
45
45
45
50
50
50
50
50
50
56
63
63
63
Thread length
mm 9
10
10
10
12
14
14
14
19
19
22
20
20
20
Shank Ø
mm 3.5
4
4.5
4.5
6
6
6
6
6
6
6
7
7
7
Shank square
mm 2.7
3
3.4
3.4
4.9
4.9
4.9
4.9
4.9
4.9
4.9
5.5
5.5
5.5
Supplier code
263 263 263 263 263 263 263 263 263 263 263 263 263 263
9105G
Per series 18,30 18,30 18,30 18,30 18,30 18,30 16,30 16,30 16,30 16,30 16,30 18,30 18,30 18,30
9107G
Finisher 9,12 9,12 9,12 9,12 9,12 9,12 8,12 8,12 8,12 8,12 8,12 9,12 9,12 9,12
Ø
mm
10
10
11
12
12
12
14
14
14
15
16
16
18
18
Pitch
mm
1
1.25
1
1
1.25 1.5
1
1.25 1.5
1
1
1.5
1
1.5
Overall length
mm 63
70
63
70
70
70
70
70
70
70
70
70
80
80
Thread length
mm 20
24
20
22
22
22
22
22
22
22
22
22
22
22
Shank Ø
mm 7
7
8
9
9
9
11
11
11
12
12
12
14
14
Shank square
mm 5.5
5.5
6.2
7
7
7
9
9
9
9
9
9
11
11
Supplier code
263 263 263 263 263 263 263 263 263 263 263 263 263 263
9105G
Per series 16,30 18,30 23,70 23,70 23,70 21,40 36,20 27,10 23,40 39,90 39,90 28,50 43,60 32,80
9107G
Finisher 8,12 9,12 11,90 11,90 11,90 10,70 18,10 13,60 11,70 20,10 20,10 14,30 21,80 16,40
Ø
mm
18
19
20
20
20
21
22
22
22
23
24
24
24
25
Pitch
mm
2
1
1
1.5
2
1
1
1.5
2
1
1
1.5
2
1
Overall length
mm 80
80
80
80
80
80
80
80
80
80
90
90
90
90
Thread length
mm 22
22
22
22
22
22
22
22
22
22
22
22
22
22
Shank Ø
mm 14
14
16
16
16
16
18
18
18
18
18
18
18
18
Shank square
mm 11
11
12
12
12
12 14.5 14.5 14.5 14.5 14.5 14.5 14.5 14.5
Supplier code
263 263 263 263 263 263 263 263 263 263 265 265 265 263
9105G
Per series 43,60 54,70 54,70 39,90 54,70 56,70 56,70 56,70 56,70 76,10 76,10 57,10 76,10 112,00
9107G
Finisher 21,80 27,40 27,10 20,10 27,40 28,40 28,40 28,40 28,40 38,10 38,10 28,50 38,10 55,60
Ø
mm
25
26
26
27
27
27
28
28
30
30
30
32
32
33
Pitch
mm
1.5
1
1.5
1
1.5
2
1
1.5
1
1.5
2
1
1.5
1.5
Overall length
mm 90
90
90
90
90
90
90
90
90
90
90
90
90
100
Thread length
mm 22
22
22
22
22
22
22
22
22
22
22
22
22
25
Shank Ø
mm 18
18
18
20
20
20
20
20
22
22
22
22
22
25
Shank square
mm 14.5 14.5 14.5 16
16
16
16
16
18
18
18
18
18
20
Supplier code
265 263 265 263 265 265 263 265 265 265 265 265 265 265
9105G
Per series 112,00 112,00 112,00 112,00 112,00 132,00 132,00 132,00 154,00 154,00 154,00 154,00 154,00 154,00
9107G
Finisher 55,60 55,60 55,60 55,60 55,60 65,50 65,50 65,50 76,90 76,90 76,90 76,90 76,90 76,90
Ø
mm
33
34
34
36
36
36
36
39
39
39
40
40
40
Pitch
mm
2
1
1.5
1
1,5
2
3
1.5
2
3
1.5
2
3
Overall length
mm 100 100 100 100 100 125 125 110 125 125 110 125 125
Thread length
mm 25
25
25
25
25
40
40
25
40
40
25
40
40
Shank Ø
mm 25
28
28
28
28
28
28
32
32
32
32
32
32
Shank square
mm 20
22
22
22
22
22
22
24
24
24
24
24
24
Supplier code
265 265 265 265 265 265 265 265 265 265 265 265 265
9105G
Per series 188,00 188,00 188,00 197,00 197,00 197,00 197,00 245,00 245,00 245,00 245,00 245,00 245,00
9107G
Finisher 94,10 94,10 94,10 98,30 98,30 98,30 98,30 123,00 123,00 123,00 123,00 123,00 123,00
HANDTAPS
