HIGH EFFICIENCY MACHINE TAPS
13
9080R
new
MF
HSS-E
TiAIN
Orig. Hartner - Art. 80831
Product description as Art. 9080P
Reduced shank, with 40° helix for deep blind holes.
Thread: Metric - Fine Pitch M - DIN 13 (DIN 374). Tolerance 6HX. Right-hand use. TiAlN coated.
For all types of steels, also for hardened non-alloy steel, stainless steel, nitrided steel, non-
oxidizable and antacid steel up to 1000 N / mm2, aluminum, its alloys and long-chipping metals.
Ø
mm
6
8
8
10
10
12
12
Pitch
mm
0,75
0,75
1
1
1,25
1
1,25
Overall length
mm 80
80
90
90
100
100
100
Thread length
mm 8
8
11
11
14
11
16
Shank Ø
mm 4,5
6
6
7
7
9
9
Shank square
mm 3,4
4,9
4,9
5,5
5,5
7
7
9080R
Each 55,60 68,10 112,00 98,80 94,90 126,00 122,00
Ø
mm
12
14
16
18
20
24
Pitch
mm
1,5
1,5
1,5
1,5
1,5
1,5
Overall length
mm 100
100
100
110
125
140
Thread length
mm 16
15
15
16
16
16
Shank Ø
mm 9
11
12
14
16
18
Shank square
mm 7
9
9
11
12
14,5
9080R
Each 121,00 153,00 183,00 206,00 246,00 305,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9080T
new
MF
HSS-E
Orig. Hartner - Art. 80751
In HSS-E steel, particularly treated for superior performance and long life. Ground and polished
after hardening. Cutting geometry optimized for maximum chip evacuation.
Reduced shank, short chamfer for through and blind holes. Thread: Metric - Fine Pitch M - DIN 13
(DIN 374). Tolerance 6HX. Right-hand use. With nitrided surface. For all types of cast iron and its
alloys, non-ferrous short chipping metals and aluminum alloys with silicon (> 6%).
Ø
mm
4
5
6
8
8
10
12
Pitch
mm
0,5
0,5
0,75
0,75
1
1
1
Overall length
mm 63
70
80
80
90
90
100
Thread length
mm 8
10
13
14
17
17
20
Shank Ø
mm 2,8
3,5
4,5
6
6
7
9
Shank square
mm 2,1
2,7
3,4
4,9
4,9
5,5
7
9080T
Each 56,60 55,60 55,60 62,30 51,80 50,80 61,40
Ø
mm
12
14
16
18
20
22
24
Pitch
mm
1,5
1,5
1,5
1,5
1,5
1,5
1,5
Overall length
mm 100
100
100
110
125
125
140
Thread length
mm 20
20
22
25
25
25
28
Shank Ø
mm 9
11
12
14
16
18
18
Shank square
mm 7
9
9
11
12
14,5
14,5
9080T
Each 54,70 70,10 81,50 95,90 122,00 124,00 148,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9081A
new
UNC
HSS-E
TiAIN
Orig. Hartner - Art. 80802
"TOP" line. In HSS-E steel, particularly treated for superior performance and long life. Ground and
polished after hardening. Cutting geometry optimized for maximum chip evacuation.
Reinforced shank (from 7/16 inches, reduced shank), short chamfer for through and blind holes .
Thread: American - UNC pitch - ANSI-B1.1 (DIN 371/376). Tolerance 2B. Right-hand use. TiAlN
coated. For all types of steels, also for hardened non-alloy steel, stainless steel, nitrided steel,
non-oxidizable and antacid sttel up to 1000 N / mm2, aluminum, its alloys and long-chipping
metals.
Thread UNC
Nr. 4 Nr. 6 Nr. 8 Nr. 10 1/4
5/16
3/8
Threads per inch
Nr
40
32
32
24
20
18
16
Overall length
mm 56
56
63
70
80
90
100
Thread length
mm 11
12
13
14
16
18
20
Shank Ø
mm 3,5
4
4,5
6
7
8
10
Shank square
mm 2,7
3
3,4
4,9
5,5
6,2
8
9081A
Each 67,10 63,30 60,40 69,10 62,30 79,60 88,20
Thread UNC
7/16
1/2
9/16
5/8
3/4
7/8
1
Threads per inch
Nr
14
13
12
11
10
9
8
Overall length
mm 100
110
110
110
125
140
160
Thread length
mm 22
25
30
30
33
35
38
Shank Ø
mm 8
9
11
12
14
18
18
Shank square
mm 6,2
7
9
9
11
14,5
14,5
9081A
Each 112,00 112,00 149,00 139,00 204,00 282,00 319,00
When the stocks will be run out, the taps will be provided with AlTiZrN coating in golden color instead of TiAlN coating.
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
