1217 / 1410
1217
Prices in EURO - VAT not included
1217
ADJUSTABLE REAMERS
13
9025
With SHORT blades and centring conical bush.
For combined or deep holes.
Cutting edges in special steel (90 Mn Cr V – AISI 02), ground. Hand use.
With drive board and cylindrical shank.
Expansion
mm
11-12 18-21 21-24 45-55
Cutting edges length
mm 48
66
77
130
Overall length
mm 208
340
365
560
Blades
Nr
5
5
5
6
9025
Each 149,00 192,00 202,00 687,00
Product running out of stock
vuoto
Spare blade for Art. 9025.
Expansion
mm
18-21 21-24 45-55
O9025
Per series 75,50 77,20 233,00
Product running out of stock
vuoto
ADJUSTABLEREAMERS
SETS OF ADJUSTABLE REAMERS
9030
Prod. SCU
Complete assortment of 11 reamers Art. 9020 ranging from 8 to 31.5mm.
In plastic case.
9030
Each 1.340,00
vuoto
SETSOFADJUSTABLEREAMERS
HIGH EFFICIENCY MACHINE TAPS
9080A
new
M
HSS-E
TiAIN
Orig. Hartner - Art. 80800
"TOP" line. In HSS-E steel, particularly treated for superior performance and long life. Ground and
polished after hardening. Cutting geometry optimized for maximum chip evacuation.
Reinforced shank (from 12mm, reduced shank), correct chamfer for through holes.
Thread: Metric - Coarse Pitch M - DIN 13 (DIN 371/376). Tolerance ISO2/6H. Right-hand use.
TiAlN coated. For all types of steels, also for hardened non-alloy steel, stainless steel, nitrided
steel, non-oxidizable and antacid steel up to 1200 N / mm2, aluminum, its alloys and long-
chipping metals.
Ø
mm
2
2,5
3
3,5
4
5
6
8
10
Pitch
mm 0,4
0,45
0,5
0,6
0,7
0,8
1
1,25
1,5
Overall length
mm 45
50
56
56
63
70
80
90
100
Thread length
mm 8
9
10
12
12
14
16
17
20
Shank Ø
mm 2,8
2,8
3,5
4
4,5
6
6
8
10
Shank square
mm 2,1
2,1
2,7
3
3,4
4,9
4,9
6,2
8
9080A
Each 50,80
47,50
39,30
50,80
39,80
39,80
52,80
58,50
72,90
Ø
mm
12
14
16
18
20
24
27
30
Pitch
mm 1,75
2
2
2,5
2,5
3
3
3,5
Overall length
mm 110
110
110
125
140
160
160
180
Thread length
mm 24
26
26
30
32
36
36
40
Shank Ø
mm 9
11
12
14
16
18
20
22
Shank square
mm 7
9
9
11
12
14,5
16
18
9080A
Each 86,30
140,00
125,00
227,00
206,00
284,00
347,00
370,00
When the stocks will be run out, the taps will be provided with AlTiZrN coating in golden color instead of TiAlN coating.
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
