1224 / 1410
1224
Prices in EURO - VAT not included
1224
MACHINE TAPS WITH DRILL
13
9089G
1/4 ,,
M
HSSG
Orig. Völkel - Art. 672
Set including tap, drill bit and countersink (90°) for quick drilling, tapping and countersinking in
only one operation.
1/4 - C6.3 hex drive to be used with screwers, drills, etc.
HSS-G for materials with resistance up to 600 N/mm². The thickness of the material must not
exceed the diameter (1xD). For through holes. Right-hand use. ISO Metric Thread - According to
DIN 13 (DIN 352).
Ø
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 36
39
41
44
50
59
Tip Ø
mm 2,5
3,3
4,2
5
6,8
8,5
9089G
Each 9,12
9,12
9,12
9,12 12,60 15,10
vuoto
MACHINETAPSWITHDRILL
ASSORTMENT OF MACHINE TAPS COMBINED WITH BIT
9089L
1/4 ,,
M
HSSG
Orig. Völkel - Art. 67200
Contents:
1 pcs. per size taps Art. 9089 G Ø 3-4-5-6-8-10mm
1 magnetic 1/4 hex shank C 6.3, for screwdrivers, drills, etc. with 1/4 E 6.3 hex drive.
In plastic case.
9089L
Each 65,50
vuoto
ASSORTMENTOFMACHINETAPSCOMBINEDWITHBIT
SHORT TAPS FOR SCREWERS
9092
1/4 ,,
M
HSSG
Orig. Völkel - Art. 670
Short type, 1/4 - C 6.3hex drive suitable for use with screwers, drills, etc.
HSS, class HSSG.
Right-hand use.
Metric ISO Thread - According to DIN 13 (DIN 352).
Ø
mm
3
4
5
6
7
8
9
10
Pitch
mm 0,5
0,7
0,8
1
1
1,25 1,25 1,5
Overall length
mm 33
35
36
39 37,5 40 40,5 41
Thread length
mm 11
12
15
18
16
19
18
21
9092
Each 4,70 4,70 5,84 5,84 7,12 8,40 11,90 9,84
vuoto
SHORTTAPSFORSCREWERS
9092B
1/4 ,,
MF
HSSG
Orig. Völkel - Art. 677
Product description as Art. 9092
METRIC ISO FINE THREAD - According to DIN 13 (DIN 2181).
Ø
mm
4
5
6
7
8
8
8
Pitch
mm
0,5
0,5
0,75
0,75
0,5
0,75
1
Overall length
mm 35
36
39
37,5
40
40
40
Thread length
mm 12
15
18
16
19
19
19
9092B
Each 6,28
7,12
7,12
9,40
9,40
9,40
9,40
Ø
mm
9
10
10
Pitch
mm
1
1
1,25
Overall length
mm 40,5
41
41
Thread length
mm 18
21
21
9092B
Each 11,90 11,90 11,90
Available on request other Ø and pitches (from Ø 3 to 10).
vuoto
SHORTTAPSFORSCREWERS
9092E
1/4 ,,
BSP
HSSG
Orig. Völkel - Art. 67870
Product description as Art. 9092
CYLINDRICAL GAS THREAD G (BSP) -According to DIN ISO 228-1 (DIN 5157).
Ø
inch 1/8
Threads per inch
Nr
28
Overall length
mm 40,5
Thread length
mm 17
9092E
Each 9,98
