1227 / 1410
1227
Prices in EURO - VAT not included
1227
HSS-CO 5% STANDARD TAPS
13
9093V
BSP
HSSG
Orig. Völkel - Art. 48628
The set contains:
No.1 tap Art. 9092 E inch 1/8
No.1 tap for each size Art. 9092 R inch 1/4-3/8-1/2-3/4-1
No.1 die for each size Art. 9368 G inch 1/8-1/4-3/8-1/2-3/4-1
In case.
9093V
Each 493,00
vuoto
HSS-CO 5%STANDARD TAPS
HAND TAPS
9095G
9097G
INOX
M
HSS-E
Orig. Völkel - Art. 573 - Art. 573-3
COBALT HSS-E
Ground and polished after hardening. RIGHT-HAND USE.
For high-resistance steel, abrasive steel and stainless steel.
ISO METRIC THREAD – According to DIN 13 (DIN 352).
M Coarse Metric – Tolerance ISO2/6H. 3pcs set.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0.5
0.7
0.8
1
1.25
1.5
1.75
Overall length
mm 40
45
50
50
56
70
75
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3.5
4.5
6
6
6
7
9
Shank square
mm 2.7
3.4
4.9
4.9
4.9
5.5
7
9095G
Per series 17,60 18,10 18,80 18,80 21,40 28,70 37,60
9097G
Finisher
5,84
5,98
6,28
6,28
7,12
9,54 12,60
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2.5
2.5
2.5
3
Overall length
mm 80
80
95
95
100
110
Thread length
mm 30
32
40
40
40
50
Shank Ø
mm 11
12
14
16
18
18
Shank square
mm 9
9
11
12
14.5
14.5
9095G
Per series 47,10 56,40 71,80 82,90 108,00 126,00
9097G
Finisher 15,70 18,80 24,10 27,70 35,90 41,90
vuoto
HAND TAPS
9100G
9102G
M
HSSG
Orig. Völkel - Art. 273 - Art. 273-3
HSSG taps.
Ground and polished after hardening.
RIGHT-HAND USE.
ISO METRIC THREAD – According to DIN 13 (DIN 352).
M Coarse Metric – Tolerance ISO 2/6H. 3Pcs set.
Ø
mm
1
1.1
1.2
1.4
1.6
1.8
2
2.2
2.3
2.5
2.6
3
3.5
Pitch
mm 0.25 0.25 0.25
0.3
0.35 0.35
0.4
0.45
0.4
0.45 0.45
0.5
0.6
Overall length
mm 32
32
32
32
32
32
36
36
36
40
40
40
45
Thread length
mm 5.5
5.5
5.5
7
8
8
8
9
9
9
9
11
13
Shank Ø
mm 2.5
2.5
2.5
2.5
2.5
2.5
2.8
2.8
2.8
2.8
2.8
3.5
4
Shank square
mm 2.1
2.1
2.1
2.1
2.1
2.1
2.1
2.1
2.1
2.1
2.1
2.7
3
9100G
Per series 43,60 43,60 43,60 43,60 43,60 43,60 18,10 18,10 18,10 18,10 18,10 9,84 14,60
9102G
Finisher 14,60 14,60 14,60 14,60 14,60 14,60 5,98 5,98 5,98 5,98 5,98 3,28 4,84
Ø
mm
4
4.5
5
6
7
8
9
10
11
12
14
16
18
Pitch
mm 0.7
0.75
0.8
1
1
1.25 1.25
1.5
1.5
1.75
2
2
2.5
Overall length
mm 45
50
50
50
50
56
63
70
70
75
80
80
95
Thread length
mm 13
16
16
19
19
22
22
24
24
29
30
32
40
Shank Ø
mm 4.5
6
6
6
6
6
7
7
8
9
11
12
14
Shank square
mm 3.4
4.9
4.9
4.9
4.9
4.9
5.5
5.5
6.2
7
9
9
11
9100G
Per series 9,84 14,60 10,70 10,70 17,60 12,60 22,30 17,30 28,20 22,70 25,70 32,10 41,10
9102G
Finisher 3,28 4,84 3,56 3,56 5,84 4,20 7,40 5,78 9,40 7,56 8,54 10,70 13,70
Ø
mm
20
22
24
27
30
33
36
42
45
48
52
Pitch
mm 2.5
2.5
3
3
3.5
3.5
4
4,5
4,5
5
5
Overall length
mm 95
100
110
110
125
125
150
150
160
180
180
Thread length
mm 40
40
50
50
56
56
63
63
70
75
75
Shank Ø
mm 16
18
18
20
22
25
28
32
36
36
40
Shank square
mm 12
14.5 14.5
16
18
20
22
24
29
29
32
9100G
Per series 47,10 59,90 68,40 114,00 146,00 197,00 235,00 347,00 419,00 594,00 594,00
9102G
Finisher 15,70 20,10 22,80 37,80 48,50 65,50 78,40 116,00 140,00 198,00 198,00
