1218 / 1410
1218
Prices in EURO - VAT not included
1218
HIGH EFFICIENCY MACHINE TAPS
13
9080B
new
M
HSS-E
TiAIN
Orig. Hartner - Art. 80830
Product description as Art. 9080A
Reinforced shank (from 12mm, reduced shank), with 40° helix for deep blind holes.
Thread: Metric - Coarse Pitch M - DIN 13 (DIN 371/376). Tolerance 6HX. Right-hand use. TiAlN
coated. For all types of steels, also for hardened non-alloy steel, stainless steel, nitrided steel,
non-oxidizable and antacid steel up to 1000 N / mm2, aluminum, its alloys and long-chipping
metals.
Ø
mm
2
3
4
5
6
8
10
Pitch
mm 0,4
0,5
0,7
0,8
1
1,25
1,5
Overall length
mm 45
56
63
70
80
90
100
Thread length
mm 4,5
6
7,5
8,5
11
14
16
Shank Ø
mm 2,8
3,5
4,5
6
6
8
10
Shank square
mm 2,1
2,7
3,4
4,9
4,9
6,2
8
9080B
Each 52,80 49,90 50,80 52,80 53,70 62,30 78,60
Ø
mm
12
14
16
18
20
24
30
Pitch
mm 1,75
2
2
2,5
2,5
3
3,5
Overall length
mm 110
110
110
125
140
160
180
Thread length
mm 18,5
20
20
25
25
30
35
Shank Ø
mm 9
11
12
14
16
18
22
Shank square
mm 7
9
9
11
12
14,5
18
9080B
Each 92,10 141,00 140,00 234,00 209,00 307,00 372,00
When the stocks will be run out,
the taps will be provided with AlTiZrN coating in golden color instead of TiAlN coating.
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9080E
new
M
HSS-E
Orig. Hartner - Art. 80750
In HSS-E steel, particularly treated for superior performance and long life. Ground and polished
after hardening. Cutting geometry optimized for maximum chip evacuation.
Reinforced shank (from 12mm, reduced shank), short chamfer for through and blind holes.
Thread: Metric - Coarse Pitch M - DIN 13 (DIN 371/376). Tolerance 6HX. Right-hand use. With
nitrided surface. For all types of cast iron and its alloys, non-ferrous short chipping metals and
aluminum alloys with silicon (> 6%).
Ø
mm
3
3,5
4
5
6
8
10
12
Pitch
mm 0,5
0,6
0,7
0,8
1
1,25 1,5 1,75
Overall length
mm 56
56
63
70
80
90
100 110
Thread length
mm 10
12
12
14
16
17
20
24
Shank Ø
mm 3,5
4
4,5
6
6
8
10
9
Shank square
mm 2,7
3
3,4
4,9
4,9
6,2
8
7
9080E
Each 27,40 30,20 27,80 28,30 28,30 32,60 39,80 48,90
Ø
mm
14
16
18
20
22
24
27
30
Pitch
mm 2
2
2,5
2,5
2,5
3
3
3,5
Overall length
mm 110 110 125 140 140 160 160 180
Thread length
mm 26
26
30
32
32
36
36
40
Shank Ø
mm 11
12
14
16
18
18
20
22
Shank square
mm 9
9
11
12 14,5 14,5 16
18
9080E
Each 75,80 71,10 122,00 116,00 209,00 151,00 246,00 248,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9080P
new
MF
HSS-E
TiAIN
Orig. Hartner - Art. 80801
"TOP" line. In HSS-E steel, particularly treated for superior performance and long life. Ground and
polished after hardening. Cutting geometry optimized for maximum chip evacuation.
Reduced shank, correct chamfer for through holes.
Thread: Metric - Fine Pitch M - DIN 13 (DIN 374). Tolerance ISO2/6H. Right-hand use. TiAlN
coated. For all types of steels, also for hardened non-alloy steel, stainless steel, nitrided steel,
non-oxidizable and antacid steel up to 1000 N / mm2, aluminum, its alloys and long-chipping
metals.
Ø
mm
3
4
5
6
6
8
8
10
10
Pitch
mm
0,35
0,5
0,5
0,5
0,75
0,75
1
1
1,25
Overall length
mm 56
63
70
80
80
80
90
90
100
Thread length
mm 7
8
10
13
13
14
17
17
20
Shank Ø
mm 2,2
2,8
3,5
4,5
4,5
6
6
7
7
Shank square
mm -
2,1
2,7
3,4
3,4
4,9
4,9
5,5
5,5
9080P
Each 65,20
58,50
60,40
62,30
78,60
83,40
87,30
91,10
94,10
Ø
mm
12
12
12
14
16
18
20
24
24
Pitch
mm
1
1,25
1,5
1,5
1,5
1,5
1,5
1,5
2
Overall length
mm 100
100
100
100
100
110
125
140
140
Thread length
mm 20
20
20
20
22
25
25
28
28
Shank Ø
mm 9
9
9
11
12
14
16
18
18
Shank square
mm 7
7
7
9
9
11
12
14,5
14,5
9080P
Each 103,00
103,00
98,80
124,00
142,00
188,00
244,00
294,00
317,00
When the stocks will be run out, the taps will be provided with AlTiZrN coating in golden color instead of TiAlN coating.
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
