1220 / 1410
1220
Prices in EURO - VAT not included
1220
HIGH EFFICIENCY MACHINE TAPS
13
9081B
new
UNC
HSS-E
TiAIN
Orig. Hartner - Art. 80832
Product description as Art. 9081A
Reinforced shank (from 7/16 inches, reduced shank), with 40° helix for deep through holes.
Thread: American - UNC pitch - ANSI-B1.1 (DIN 371/376). Tolerance 2B. Right-hand use. TiAlN
coated. For all types of steels, also for hardened non-alloy steel, stainless steel, nitrided steel,
non-oxidizable and antacid steel up to 1000 N / mm2, aluminum, its alloys and long-chipping
metals.
Thread UNC
Nr. 4 Nr. 6 Nr. 8 Nr. 10 1/4
5/16
3/8
Threads per inch
Nr
40
32
32
24
20
18
16
Overall length
mm 56
56
63
70
80
90
100
Thread length
mm 7
8
8
11
13
14
16
Shank Ø
mm 3,5
4
4,5
6
7
8
10
Shank square
mm 2,7
3
3,4
4,9
5,5
6,2
8
9081B
Each 68,10 61,40 68,10 69,10 68,10 71,10 79,60
Thread UNC
7/16
1/2
9/16
5/8
3/4
7/8
Threads per inch
Nr
14
13
12
11
10
9
Overall length
mm 100
110
110
110
125
140
Thread length
mm 18
20
21
24
25
28
Shank Ø
mm 8
9
11
12
14
18
Shank square
mm 6,2
7
9
9
11
14,5
9081B
Each 107,00 104,00 153,00 147,00 192,00 271,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9081E
new
UNC
HSS-E
Orig. Hartner - Art. 80752
In HSS-E steel, particularly treated for superior performance and long life. Ground and polished
after hardening. Cutting geometry optimized for maximum chip evacuation.
Reinforced shank (from 7/16 inches, reduced shank), short chamfer for through and blind holes .
Thread: American - UNC pitch - ANSI-B1.1 (DIN 371/376). Tolerance 2B. Right-hand use. With
nitrided surface. For all types of cast iron and its alloys, non-ferrous short chipping metals and
aluminum alloys with silicon (> 6%).
Thread UNC
Nr. 4 Nr. 6 Nr. 8 Nr. 10 1/4
5/16
3/8
Threads per inch
Nr
40
32
32
24
20
18
16
Overall length
mm 56
56
63
70
80
90
100
Thread length
mm 11
12
13
14
16
18
20
Shank Ø
mm 3,5
4
4,5
6
7
8
10
Shank square
mm 2,7
3
3,4
4,9
5,5
6,2
8
9081E
Each 41,70 35,10 40,30 40,30 36,50 42,70 48,10
Thread UNC
7/16
1/2
9/16
5/8
3/4
7/8
1
Threads per inch
Nr
14
13
12
11
10
9
8
Overall length
mm 100
110
110
110
125
140
160
Thread length
mm 22
25
30
30
33
35
38
Shank Ø
mm 8
9
11
12
14
18
18
Shank square
mm 6,2
7
9
9
11
14,5
14,5
9081E
Each 62,30 65,20 118,00 96,80 128,00 158,00 198,00
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
HIGHEFFICIENCYMACHINETAPS
9081P
new
UNF
HSS-E
TiAIN
Orig. Hartner - Art. 80803
"TOP" line. In HSS-E steel, particularly treated for superior performance and long life. Ground and
polished after hardening. Cutting geometry optimized for maximum chip evacuation.
Reduced shank, correct chamfer for through holes.
Thread: American - UNF Pitch - ANSI-B1.1 (DIN 374). Tolerance 2B. Right-hand use. TiAlN
coated. For all types of steels, also for hardened non-alloy steel, stainless steel, nitrided steel,
non-oxidizable and antacid steel up to 1000 N / mm2, aluminum, its alloys and long-chipping
metals.
Thread UNF
Nr. 4
Nr. 6
Nr. 8
Nr. 10
1/4
5/16
3/8
7/16
5/8
7/8
1
Threads per inch
Nr
48
40
36
32
28
24
24
20
18
14
12
Overall length
mm 56
56
63
70
80
90
90
90
100
125
140
Thread length
mm 10
11
12
14
16
18
18
18
22
25
28
Shank Ø
mm 2,2
2,5
2,8
3,5
4,5
6
7
8
12
18
18
Shank square
mm -
2,1
2,1
2,7
3,4
4,9
5,5
6,2
9
14,5
14,5
9081P
Each 69,10
65,20
69,10
72,90
94,10
75,80 106,00 115,00 158,00 255,00 370,00
When the stocks will be run out, the taps will be provided with AlTiZrN coating in golden color instead of TiAlN coating.
For Ø holes for tapping see technical tables and tips Art. 8400 G - 8500 G.
vuoto
