1244 / 1410
1244
Prices in EURO - VAT not included
1244
MACHINE TAP WITH COLOURED RINGS
13
MACHINE TAP WITH COLOURED RINGS
9288G
INOX
MF
HSS-E
VAP
Orig. Völkel - Art. 359
WHITE collar.
Stainless SUPER-FAST class HSS-E, especially treated for superior performance.
Vaporized. Ground and polished after hardening.
Through shank, proper chamfer for through holes.
Thread: Metric ISO FINE - MF - DIN 13 (DIN 374) compliant.
Right hand use.
For all types of stainless steel and long swarf steels with R up to 1000 N/mm².
Ø
mm
5
6
8
8
10
10
12
12
14
16
18
20
Pitch
mm
0,5
0,75
0,75
1
1
1,25
1,25
1,5
1,5
1,5
1,5
1,5
Overall length
mm 70
80
80
90
90
100
100
100
100
100
110
125
Thread length
mm 12
14
19
22
20
24
22
22
22
22
25
25
Shank Ø
mm 3,5
4,5
6
6
7
7
9
9
11
12
14
16
Shank square
mm 2,7
3,4
4,9
4,9
5,5
5,5
7
7
9
9
11
12
9288G
Each 23,50 23,50 23,50 23,50 27,50 27,50 37,60 37,60 47,10 54,20 65,80 73,10
MACHINETAPWITHCOLOUREDRINGS
9290G
INOX
MF
HSS-E
VAP
Orig. Völkel - Art. 369
Product description as Art. 9288G
Through shank, 39° spiral flute for deep blind holes.
Thread: Metric ISO FINE - MF - DIN 13 (DIN 374) compliant.
Right hand use.
For all types of stainless steel and long swarf steels with R up to 1000 N/mm².
Ø
mm
5
6
8
8
10
10
12
12
14
16
18
20
Pitch
mm
0,5
0,75
0,75
1
1
1,25
1,25
1,5
1,5
1,5
1,5
1,5
Overall length
mm 70
80
80
90
90
100
100
100
100
100
110
125
Thread length
mm 5
8
8
10
10
16
15
15
15
15
17
17
Shank Ø
mm 3,5
4,5
6
6
7
7
9
9
11
12
14
16
Shank square
mm 2,7
3,4
4,9
4,9
5,5
5,5
7
7
9
9
11
12
9290G
Each 26,70 26,70 26,70 26,70 32,10 31,70 40,80 40,80 50,20 58,10 72,10 79,90
MACHINETAPWITHCOLOUREDRINGS
MACHINE TAPS
9292G
BSW
HSS-E
Orig. Völkel - Art. 705
REINFORCED SHANK
RIGHT-HAND USE
BSW WHITWORTH THREAD – According to DIN 11 (DIN 371)
HSS-E. Proper chamfer. Universal type. Through holes.
Ø
inch
1/8
3/16
1/4
5/16
3/8
Threads per inch
Nr
40
24
20
18
16
Overall length
mm 56
70
80
90
100
Thread length
mm 11
15
17
20
22
Shank Ø
mm 3,5
6
7
8
9
Shank square
mm 2,7
4,9
5,5
6,2
7
9292G
Each 11,70
11,70
11,70
14,90
16,60
vuoto
MACHINETAPS
9293G
BSW
HSS-E
Orig. Völkel - Art. 707
Product description as Art. 9292G
HSS-E. Short chamfer. With 35° right-hand spiral flute for metals up to R 900 N/mm². Deep blind
holes.
Ø
inch
1/8
3/16
1/4
5/16
3/8
Threads per inch
Nr
40
24
20
18
16
Overall length
mm 56
70
80
90
100
Thread length
mm 7
10
13
14
16
Shank Ø
mm 3,5
6
7
8
9
Shank square
mm 2,7
4,9
5,5
6,2
7
9293G
Each 14,60
14,60
14,60
18,10
20,10
MACHINETAPS
9298G
BSW
HSS-E
Orig. Völkel - Art. 715
REDUCED SHANK.
RIGHT-HAND USE.
BSW WHITWORTH THREAD – According to DIN 11 (DIN 376)
HSS-E. Proper chamfer. Universal type. Through holes.
Ø
inch
1/2
5/8
3/4
7/8
1
Threads per inch
Nr
12
11
10
9
8
Overall length
mm 110
110
125
140
160
Thread length
mm 25
27
30
32
36
Shank Ø
mm 9
12
14
18
20
Shank square
mm 7
9
11
14,5
16
9298G
Each 19,70
29,90
57,70
70,50
79,80
MACHINETAPS
