1247 / 1410
1247
Prices in EURO - VAT not included
1247
MACHINE TAPS
13
9321G
new
BSP
HSS-E
TIN
Product description as Art. 9320G
HSS-E. Correct chamfer. Universal type. Through holes. TIN coated.
Ø
inch
1/8
1/4
3/8
1/2
3/4
1
Threads per inch
Nr
28
19
19
14
14
11
Overall length
mm 90
100
100
125
140
160
Thread length
mm 20
22
22
25
28
30
Shank Ø
mm 7
11
12
16
20
25
Shank square
mm 5,5
9
9
12
16
20
9321G
Each 28,20 39,60 51,20 87,50 124,00 191,00
vuoto
MACHINETAPS
9322G
BSP
HSS-E
Orig. Völkel - Art. 784
Product description as Art. 9320G
HSS-E. Short chamfer. Universal type. Blind holes.
Ø
inch
1/8
1/4
3/8
1/2
5/8
3/4
1
Threads per inch
Nr
28
19
19
14
14
14
11
Overall length
mm 90
100
100
125
125
140
160
Thread length
mm 20
22
22
25
25
28
30
Shank Ø
mm 7
11
12
16
18
20
25
Shank square
mm 5,5
9
9
12
14,5
16
20
9322G
Each 18,10 22,80 28,50 39,90 45,60 59,10 85,50
Ø
inch
1.1/8 1.1/4 1.3/8 1.1/2
Threads per inch
Nr
11
11
11
11
Overall length
mm 170
170
180
190
Thread length
mm 30
30
32
32
Shank Ø
mm 28
32
36
36
Shank square
mm 22
24
29
29
9322G
Each 119,00 161,00 190,00 225,00
vuoto
MACHINETAPS
9323G
new
BSP
HSS-E
TIN
Product description as Art. 9320G
HSS-E. Short chamfer. Universal type. Through and blind holes. TIN coated.
Ø
inch
1/8
1/4
3/8
1/2
3/4
1
Threads per inch
Nr
28
19
19
14
14
11
Overall length
mm 90
100
100
125
140
160
Thread length
mm 20
22
22
25
28
30
Shank Ø
mm 7
11
12
16
20
25
Shank square
mm 5,5
9
9
12
16
20
9323G
Each 27,40 38,50 51,20 85,50 121,00 180,00
vuoto
MACHINETAPS
9324G
BSP
HSS-E
Orig. Völkel - Art. 787
Product description as Art. 9320G
HSS-E. Short chamfer. Type with approx. 35° spiral flute for metals up to R 900 N/mm². Deep
blind holes.
Ø
inch
1/8
1/4
3/8
1/2
3/4
7/8
1
Threads per inch
Nr
28
19
19
14
14
14
11
Overall length
mm 90
100
100
125
140
150
160
Thread length
mm 20
22
22
25
28
28
30
Shank Ø
mm 7
11
12
16
20
22
25
Shank square
mm 5,5
9
9
12
16
18
20
9324G
Each 21,40 27,50 34,20 47,90 71,80 84,50 105,00
Ø
inch
1.1/4 1.1/2
Threads per inch
Nr
11
11
Overall length
mm 170
190
Thread length
mm 30
32
Shank Ø
mm 32
36
Shank square
mm 24
29
9324G
Each 195,00 272,00
vuoto
MACHINETAPS
9325G
new
BSP
HSS-E
TIN
Product description as Art. 9320G
HSS-E. Short chamfer. Type with approx. 35° spiral flute for metals up to R 900 N/mm², for alloyed
and unalloyed steel. Deep blind holes. TIN coated
Ø
inch
1/8
1/4
3/8
1/2
3/4
1
Threads per inch
Nr
28
19
19
14
14
11
Overall length
mm 90
100
100
125
140
160
Thread length
mm 20
22
22
25
28
30
Shank Ø
mm 7
11
12
16
20
25
Shank square
mm 5,5
9
9
12
16
20
9325G
Each 30,70 43,20 56,90 93,50 134,00 199,00
vuoto
MACHINETAPS
