1246 / 1410
1246
Prices in EURO - VAT not included
1246
MACHINE TAPS
13
9314G
UNF
HSS-E
Orig. Völkel - Art. 765
REINFORCED SHANK
RIGHT-HAND USE
UNF AMERICAN THREAD- According to ANSI-B1.1 (DIN 371)
HSS-E. Proper chamfer. Universal type. Through holes.
Thread UNF
Nr. 4 Nr. 5 Nr. 6 Nr. 8 Nr. 10 Nr. 12 1/4 5/16 3/8
Threads per inch
Nr
48 44 40 36 32 28 28 24 24
Overall length
mm 50 56 56 63 70 70 80 90 100
Thread length
mm 10 11 12 13 15 16 17 17 18
Shank Ø
mm 3,5 3,5
4
4,5
6
6
7
8
9
Shank square
mm 2,7 2,7
3
3,4 4,9 4,9 5,5 6,2
7
9314G
Each 11,70 11,70 11,70 11,70 11,70 11,70 11,70 14,90 16,60
vuoto
MACHINETAPS
9315G
UNF
HSS-E
Orig. Völkel - Art. 767
Product description as Art. 9314G
HSS-E. Short chamfer. With 35° right-hand spiral flute for structural steel; for metals up to R 900
N/mm². Deep blind holes.
Thread UNF
1/4
5/16
3/8
Threads per inch
Nr
28
24
24
Overall length
mm 80
90
100
Thread length
mm 10
10
10
Shank Ø
mm 7
8
9
Shank square
mm 5,5
6,2
7
9315G
Each 14,60 18,10 20,10
vuoto
MACHINETAPS
9315GE
UNF
HSS-E
Orig. Völkel - Art. 775
REDUCED SHANK
RIGHT-HAND USE
UNF AMERICAN THREAD according to ANSI-B1.1 (DIN 376)
HSS-E. Proper chamfer. Universal type. Through holes.
Thread UNF
7/16
1/2
5/8
3/4
1
Threads per inch
Nr
20
20
18
16
12
Overall length
mm 100
100
100
110
150
Thread length
mm 22
22
22
25
28
Shank Ø
mm 8
9
12
14
20
Shank square
mm 6.2
7
9
11
16
9315GE
Each 19,70 19,70 29,90 57,70 79,80
vuoto
MACHINETAPS
9315GP
UNF
HSS-E
Orig. Völkel - Art. 777
Product description as Art. 9315GE
HSS-E. Short chamfer. With 35° right-hand spiral flute for structural steel; for metals up to R 900
N/mm². Blind holes.
Thread UNF
7/16
1/2
5/8
3/4
1
Threads per inch
Nr
20
20
18
16
12
Overall length
mm 100
100
100
110
150
Thread length
mm 13
13
15
17
20
Shank Ø
mm 8
9
12
14
20
Shank square
mm 6,2
7
9
11
16
9315GP
Each 24,50 24,50 36,20 72,10 98,30
vuoto
MACHINETAPS
9320G
BSP
HSS-E
Orig. Völkel - Art. 785
REDUCED SHANK.
RIGHT-HAND USE.
CYLINDRICAL GAS THREAD G (BSP) – According to DIN ISO 228
HSS-E. Correct chamfer. Universal type. Through holes.
Ø
inch
1/8
1/4
3/8
1/2
5/8
3/4
7/8
Threads per inch
Nr
28
19
19
14
14
14
14
Overall length
mm 90
100
100
125
125
140
150
Thread length
mm 20
22
22
25
25
28
28
Shank Ø
mm 7
11
12
16
18
20
22
Shank square
mm 5,5
9
9
12
14,5
16
18
9320G
Each 19,10 24,10 28,50 41,90 47,90 62,40 77,70
Ø
inch
1
1.1/8 1.1/4 1.3/8 1.1/2
Threads per inch
Nr
11
11
11
11
11
Overall length
mm 160
170
170
180
190
Thread length
mm 30
30
30
32
32
Shank Ø
mm 25
28
32
36
36
Shank square
mm 20
22
24
29
29
9320G
Each 96,40 142,00 171,00 223,00 241,00
vuoto
MACHINETAPS
