MACHINE TAP WITH COLOURED RINGS
13
9272GP
INOX
M
HSS-E
VAP
Orig. Völkel - Art. 362
Product description as Art. 9272GL
Reinforced shank (12mm, reduced shank), with 39° spiral flute for deep blind holes.
Thread: Coarse Metric M - DIN 13 (DIN 371/376).
Right-hand use.
For all kinds of stainless steel and long chip steel with R up to 1000 N/mm².
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 6
7
8
10
14
16
18
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9272GP
Each 16,30 16,30 17,80 17,80 20,70 28,50 36,60
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 20
22
25
25
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9272GP
Each 41,30 45,20 61,10 84,60
Taps with similar characteristics for UNC, UNF and G (BSP) threads can be supplied on request.
vuoto
MACHINETAPWITHCOLOUREDRINGS
9272GR
INOX
M
HSS-E
Orig. Völkel - Art. 354
BLUE collar.
Stainless SUPER-FAST class HSS-E, especially treated for superior performance.
Ground and polished after hardening.
Reinforced shank (12mm, reduced shank), correct chamfer for through holes.
Thread: Coarse Metric M - DIN 13 (DIN 371/376).
Right-hand use.
For all kinds of stainless steel and short chip steel with R up to 1200 N/mm², as well as short chip
titanium.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9272GR
Each 12,40 12,40 13,60 13,60 15,70 21,70 27,80
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 30
32
34
34
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9272GR
Each 31,40 34,20 46,30 64,10
vuoto
MACHINETAPWITHCOLOUREDRINGS
9272GRE
new
INOX
M
HSS-E
TiCN
Product description as Art. 9272GR
Reinforced shank (from 12mm, reduced shank), correct chamfer for through holes.
Thread: Metric - Coarse Pitch M - DIN 13 (DIN 371/376). Right-hand use. For all types of
stainless steels and short-chipping steels with tensile strength up to 1200 N / mm², short chipping
titanium.
With TiCN coating.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9272GRE
Each 16,80 16,80 18,10 18,80 22,40 30,90 41,90
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 30
32
34
34
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9272GRE
Each 47,10 51,30 69,10 86,80
