ROUND DIES
13
9366G
UNF
HSS
Orig. Völkel - Art. 244
Product description as Art. 9350G
UNF AMERICAN THREAD, according to ANSI-B1.1
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 600 N/mm².
Thread UNF
Nr. 1 Nr. 2 Nr. 3 Nr. 4 Nr. 5 Nr. 6 Nr. 8
Threads per inch
Nr
72
64
56
48
44
40
36
Dimensions
mm 16x5 16x5 16x5 20x5 20x5 20x5 20x7
9366G
Each 26,80 26,80 26,80 18,60 18,60 18,60 18,60
Thread UNF
Nr. 10 Nr. 12 1/4
5/16
3/8
7/16
1/2
Threads per inch
Nr
32
28
28
24
24
20
20
Dimensions
mm 20x7 20x7 20x7 25x9 30x11 30x11 38x10
9366G
Each 18,60 18,60 14,30 16,40 18,10 21,10 23,50
Thread UNF
9/16
5/8
3/4
7/8
1
Threads per inch
Nr
18
18
16
14
12
Dimensions
mm 38x10 45x14 45x14 55x16 55x16
9366G
Each 29,10 31,80 31,80 49,20 49,20
vuoto
ROUNDDIES
9368G
BSP
HSS
Orig. Völkel - Art. 254
Closed type, fully ground according to DIN-EN 24231.
CYLINDRICAL GAS THREAD G (BSP), according to DIN 228-1
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm².
Ø
inch
1/8
1/4
3/8
1/2
5/8
3/4
7/8
Threads per inch
Nr
28
19
19
14
14
14
14
Dimensions
mm 30x11 38x10 45x14 45x14 55x16 55x16 65x18
9368G
Each 21,40 21,40 28,50 28,50 47,70 47,70 64,40
Ø
inch
1
1.1/8 1.1/4 1.3/8 1.1/2 1.3/4
2
Threads per inch
Nr
11
11
11
11
11
11
11
Dimensions
mm 65x18 75x20 75x20 90x22 90x22 105x22 105x22
9368G
Each 64,40 98,30 98,30 167,00 167,00 349,00 349,00
vuoto
ROUNDDIES
9370G
NPT
HSS
Orig. Völkel - Art. 236
Closed type, fully ground.
NPT AMERICAN THREAD - Taper 1:16.
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm².
Ø
inch
1/8
1/4
3/8
1/2
3/4
1
1.1/4
Threads per inch
Nr
27
18
18
14
14
11 1/2 11 1/2
Dimensions
mm 30x11 38x14 45x14 45x18 55x22 65x25 75x26
9370G
Each 45,60 55,60 69,80 69,80 113,00 167,00 197,00
Ø
inch
1.1/2
2
Threads per inch
Nr
11 1/2 11 1/2
Dimensions
mm 90x27 105x28
9370G
Each 321,00 425,00
vuoto
ROUNDDIES
9372G
BSPT
HSS
Orig. Völkel - Art. 970
Fully configured.
R CONICAL GAS THREAD (BSPT) with 1:16 55° taper.
RIGHT HAND USE
In HSS steel, normal chamfer, for steels with R up to 800 N/mm².
Ø
inch
1/8
1/4
3/8
1/2
3/4
1
1.1/4
Threads per inch
Nr
28
19
19
14
14
11
11
Dimensions
mm 38x11 38x16 50x18 50x22 50x24 63x28 75x32
9372G
Each 22,80 22,80 46,30 46,30 46,30 76,90 104,00
vuoto
ROUNDDIES
9374G
PG
HSS
Orig. Völkel - Art. 258
Closed, completely ground.
PG thread in accordance with DIN 40430.
USE RIGHT
In steel HSS, normal chamfer, for steels with R up to 800 N/mm².
Ø
inch
7
9
11
13,5
16
21
29
Threads per inch
Nr
20
18
18
18
18
16
16
Dimensions
mm 38x10 45x14 45x14 45x14 55x16 65x18 65x18
9374G
Each 52,70 64,10 64,10 64,10 75,50 117,00 117,00
vuoto
