1239 / 1410
1239
Prices in EURO - VAT not included
1239
MACHINE TAP WITH COLOURED RINGS
13
9271GP
M
HSS-E
Orig. Völkel - Art. 363
GREEN collar.
Stainless SUPER-FAST class HSS-E, especially treated for superior performance.
Ground and polished after hardening.
Reinforced shank (12mm, reduced shank), with 35° spiral flute for deep blind holes.
Thread: Coarse Metric M - DIN 13 (DIN 371/376).
Right-hand use.
For steel up to 1000 N/sqmm, cast iron, aluminium, copper brass, and other long chip materials.
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 6
7
8
10
14
16
18
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9271GP
Each 14,90 14,90 16,30 16,30 18,80 26,10 33,40
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 20
22
25
25
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9271GP
Each 37,60 41,10 55,60 76,90
vuoto
MACHINETAPWITHCOLOUREDRINGS
9271GR
new
M
HSSE-PM-TIN
Orig. Völkel - Art. 301
GREEN collar.
Sintered SUPER-FAST class HSS-E steel, TIN coated, for superior performance.
Ground and polished after hardening.
Reinforced shank (from 12mm, reduced shank), with 39° helix for deep blind holes.
Thread: Metric - Coarse Pitch M - DIN 13 (DIN 371/376). Right-hand use. For non- and low-alloy
steel up to 1000 N / mm², stainless steel and alloys, aluminum, copper and alloys, and long-
chipping materials.
Ø
mm
3
4
5
6
8
10 12 14 16
Pitch
mm 0,5 0,7 0,8
1 1,25 1,5 1,75 2
2
Overall length
mm 56 63 70 80 90 100 110 110 110
Thread length
mm 6
7
8
10 14 16 18 20 22
Shank Ø
mm 3,5 4,5
6
6
8
10
9
11 12
Shank square
mm 2,7 3,4 4,9 4,9 6,2
8
7
9
9
9271GR
Each 29,20 29,20 31,40 34,90 42,80 54,90 75,50 117,00 132,00
vuoto
MACHINETAPWITHCOLOUREDRINGS
9272GL
INOX
M
HSS-E
VAP
Orig. Völkel - Art. 352
WHITE collar.
Stainless SUPER-FAST class HSS-E, especially treated for superior performance.
Vaporized. Ground and polished after hardening.
Reinforced shank (12mm, reduced shank), with chamfer suitable for through holes.
Thread: Coarse Metric M - DIN 13 (DIN 371/376).
Right-hand use.
For all kinds of stainless steel and long chip steel with R up to 1000 N/mm².
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9272GL
Each 13,60 13,60 14,90 14,90 17,30 23,80 30,50
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 30
32
34
34
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9272GL
Each 34,50 37,60 50,90 70,50
Taps with similar characteristics for UNC, UNF and G (BSP) threads can be supplied on request.
vuoto
MACHINETAPWITHCOLOUREDRINGS
