1245 / 1410
1245
Prices in EURO - VAT not included
1245
MACHINE TAPS
13
9299G
BSW
HSS-E
Orig. Völkel - Art. 717
Product description as Art. 9298G
HSS-E. Short chamfer. With 35° right-hand spiral flute for metals up to R 900 N/mm². Deep blind
holes.
Ø
inch
1/2
5/8
3/4
7/8
1
Threads per inch
Nr
12
11
10
9
8
Overall length
mm 110
110
125
140
160
Thread length
mm 20
22
25
27
30
Shank Ø
mm 9
12
14
18
20
Shank square
mm 7
9
11
14,5
16
9299G
Each 24,50
36,20
72,10
87,50
98,30
vuoto
MACHINETAPS
9307G
UNC
HSS-E
Orig. Völkel
REINFORCED SHANK
RIGHT-HAND USE
UNC AMERICAN THREAD – According to ANSI-B1.1 (DIN 371)
HSS-E. Proper chamfer. Universal type. Through holes.
Thread UNC
Nr. 2 Nr. 4 Nr. 5 Nr. 6 Nr. 8 Nr. 10 Nr. 12
Threads per inch
Nr
56
40
40
32
32
24
24
Overall length
mm 45
50
56
56
63
70
70
Thread length
mm 8
10
11
12
13
15
16
Shank Ø
mm 2,8
3,5
3,5
4
4,5
6
6
Shank square
mm 2,1
2,7
2,7
3
3,4
4,9
4,9
9307G
Each 22,70 11,70 11,70 11,70 11,70 11,70 11,70
Thread UNC
1/4
5/16
3/8
Threads per inch
Nr
20
18
16
Overall length
mm 80
90
100
Thread length
mm 17
20
22
Shank Ø
mm 7
8
9
Shank square
mm 5,5
6,2
7
9307G
Each 11,70 14,90 16,60
Misura Nr. 2 in esaurimento.
vuoto
MACHINETAPS
9309G
UNC
HSS-E
Orig. Völkel - Art. 747
Product description as Art. 9307G
HSS-E. Short chamfer. With 35° right-hand spiral flute for or metals up to R 900 N/mm². Blind
holes.
Thread UNC
Nr. 6 Nr. 8 Nr. 10 Nr. 12 1/4
5/16
3/8
Threads per inch
Nr
32
32
24
24
20
18
16
Overall length
mm 56
63
70
70
80
90
100
Thread length
mm 7
8
10
10
13
14
16
Shank Ø
mm 4
4,5
6
6
7
8
9
Shank square
mm 3
3,4
4,9
4,9
5,5
6,2
7
9309G
Each 14,60 14,60 14,60 14,60 14,60 18,10 20,10
vuoto
MACHINETAPS
9311GC
UNC
HSS-E
Orig. Völkel - Art. 755
REDUCED SHANK.
RIGHT-HAND USE.
UNC AMERICAN THREAD – According to ANSI-B1.1 (DIN 376)
HSS-E. Proper chamfer. Universal type. Through holes.
Thread UNC
7/16
1/2
9/16
5/8
3/4
7/8
1
Threads per inch
Nr
14
13
12
11
10
9
8
Overall length
mm 100
110
110
110
125
140
160
Thread length
mm 22
25
26
27
30
32
36
Shank Ø
mm 8
9
11
12
14
18
20
Shank square
mm 6,2
7
9
9
11
14,5
16
9311GC
Each 19,70 19,70 29,90 29,90 57,70 70,50 79,80
vuoto
MACHINETAPS
9311GD
UNC
HSS-E
Orig. Völkel - Art. 757
Product description as Art. 9311GC
HSS-E. Short chamfer. With 35° right-hand spiral flute for structural steel; for metals up to R 900
N/mm². Blind holes.
Thread UNC
7/16
1/2
9/16
5/8
3/4
7/8
1
Threads per inch
Nr
14
13
12
11
10
9
8
Overall length
mm 100
110
110
110
125
140
160
Thread length
mm 17
20
20
22
25
27
30
Shank Ø
mm 8
9
11
12
14
18
20
Shank square
mm 6,2
7
9
9
11
14,5
16
9311GD
Each 24,50 24,50 36,20 36,20 72,10 87,50 98,30
vuoto
