ROUND DIES
13
Ø
mm
25
26
26
27
27
27
28
28
30
30
30
32
32
33
Pitch
mm
1,5
1
1,5
1
1,5
2
1
1,5
1
1,5
2
1
1,5
1,5
Dimensions
mm 55x16 55x16 55x16 65x18 65x18 65x18 65x18 65x18 65x18 65x18 65x18 65x18 65x18 65x18
9357G
Each 69,80 69,80 69,80 79,80 79,80 79,80 79,80 79,80 79,80 79,80 79,80 113,00 79,80 79,80
Ø
mm
33
34
34
36
36
36
36
39
39
39
40
40
40
Pitch
mm
2
1
1,5
1
1,5
2
3
1,5
2
3
1,5
2
3
Dimensions
mm 65x18 65x18 65x18 65x18 65x18 65x18 65x25 75x20 75x20 75x30 75x20 75x20 75x30
9357G
Each 79,80 113,00 79,80 113,00 79,80 79,80 79,80 129,00 129,00 129,00 129,00 129,00 129,00
vuoto
ROUNDDIES
9358G
LEFT USAGE
MF
HSS
Orig. Völkel - Art. 262
Product description as Art. 9350G
ISO FINE METRIC THREAD, according to DIN 13 - MF Fine Metric – Tolerance 6g
LEFT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm².
Ø
mm
3
3,5
4
5
6
6
8
8
Pitch
mm
0,35 0,5
0,5
0,5
0,5 0,75 0,75
1
Dimensions
mm 20x5 20x5 20x5 20x5 20x5 20x7 25x9 25x9
9358G
Each 19,30 19,30 19,30 19,30 19,30 19,30 22,80 22,80
Ø
mm
10
10
12
12
12
14
14
14
Pitch
mm
1
1,25
1
1,25 1,5
1
1,25 1,5
Dimensions
mm 30x11 30x11 38x10 38x10 38x10 38x10 38x10 38x10
9358G
Each 28,50 28,50 37,10 37,10 37,10 37,10 37,10 37,10
Ø
mm
16
16
18
20
22
24
24
30
Pitch
mm
1
1,5
1,5
1,5
1,5
1,5
2
2
Dimensions
mm 45x14 45x14 45x14 45x14 55x16 55x16 55x16 65x18
9358G
Each 55,60 55,60 55,60 55,60 88,30 88,30 88,30 140,00
vuoto
ROUNDDIES
9360G
BSW
HSS
Orig. Völkel - Art. 224
Product description as Art. 9350G
BSW WHITWORTH THREAD, according to BS 84
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm².
Ø
inch
1/8
5/32
3/16
7/32
1/4
5/16
3/8
Threads per inch
Nr
40
32
24
24
20
18
16
Dimensions
mm 20x5 20x5 20x7 20x7 20x7 25x9 30x11
9360G
Each 14,30 14,30 14,30 14,30 14,30 16,40 18,10
Ø
inch
7/16
1/2
9/16
5/8
3/4
7/8
1
Threads per inch
Nr
14
12
12
11
10
9
8
Dimensions
mm 30x11 38x14 38x14 45x18 45x18 55x22 55x22
9360G
Each 21,10 23,50 29,10 31,80 31,80 49,20 49,20
vuoto
ROUNDDIES
9362G
BSF
HSS
Orig. Völkel - Art. 228
Product description as Art. 9350G
BSF FINE WHITWORTH THREAD (BS 84 STANDARD)
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm².
Ø
inch
3/16
1/4
5/16
3/8
7/16
1/2
5/8
Threads per inch
Nr
32
26
22
20
18
16
14
Dimensions
mm 20x7 20x7 25x9 30x11 30x11 38x10 45x14
9362G
Each 14,30 14,30 16,40 18,80 21,10 28,20 42,80
Ø
inch
3/4
7/8
1
Threads per inch
Nr
12
11
10
Dimensions
mm 45x14 55x22 55x22
9362G
Each 42,80 55,60 55,60
vuoto
ROUNDDIES
9364G
UNC
HSS
Orig. Völkel - Art. 234
Product description as Art. 9350G
UNC AMERICAN THREAD, according to ANSI-B1.1
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm².
Thread UNC
Nr. 1 Nr. 2 Nr. 3 Nr. 4 Nr. 5 Nr. 6 Nr. 8
Threads per inch
Nr
64
56
48
40
40
32
32
Dimensions
mm 16x5 16x5 16x5 20x5 20x5 20x7 20x7
9364G
Each 26,80 26,80 26,80 18,60 18,60 18,60 18,60
Thread UNC
Nr. 10 Nr. 12 1/4
5/16
3/8
7/16
1/2
Threads per inch
Nr
24
24
20
18
16
14
13
Dimensions
mm 20x7 20x7 20x7 25x9 30x11 30x11 38x14
9364G
Each 18,60 18,60 14,30 16,40 18,10 21,10 23,50
Thread UNC
9/16
5/8
3/4
7/8
1
Threads per inch
Nr
12
11
10
9
8
Dimensions
mm 38x14 45x18 45x18 55x22 55x22
9364G
Each 29,10 31,80 31,80 49,20 49,20
vuoto
