1248 / 1410
1248
Prices in EURO - VAT not included
1248
ROUND DIES
13
ROUND DIES
9350G
M
HSS
Orig. Völkel - Art. 274
Closed type, fully ground according to DIN-EN 22568.
ISO METRIC THREAD, according to DIN 13 – M Coarse Metric -Tolerance 6g
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm².
Ø
mm
1
1,1
1,2
1,4
1,6
1,8
2
2,2
2,3
2,5
2,6
3
3,5
4
Pitch
mm 0,25 0,25 0,25 0,3 0,35 0,35 0,4 0,45 0,40 0,45 0,45 0,5
0,6
0,7
Dimensions
mm 16x5 16x5 16x5 16x5 16x5 16x5 16x5 16x5 16x5 16x5 16x5 20x5 20x5 20x5
9350G
Each 16,40 16,40 16,40 16,40 16,40 14,30 14,30 14,30 14,30 14,30 14,30 6,84 10,60 6,84
Ø
mm
4,5
5
6
7
8
9
10
11
12
14
16
18
20
22
Pitch
mm 0,75 0,8
1
1
1,25 1,25 1,5
1,5 1,75
2
2
2,5
2,5
2,5
Dimensions
mm 20x7 20x7 20x7 25x9 25x9 25x9 30x11 30x11 38x14 38x14 45x18 45x18 45x18 55x22
9350G
Each 10,60 7,26 7,26 11,40 7,70 13,10 9,90 15,10 15,90 16,40 25,40 25,40 25,40 45,90
Ø
mm
24
27
30
33
36
42
45
48
52
Pitch
mm 3
3
3,5
3,5
4
4,5
4,5
5
5
Dimensions
mm 55x22 65x25 65x25 65x25 65x25 75x30 90x36 90x36 90x36
9350G
Each 45,90 64,40 64,40 64,40 64,40 104,00 178,00 178,00 178,00
ROUNDDIES
9353G
LEFT USAGE
M
HSS
Orig. Völkel - Art. 272
Product description as Art. 9350G
ISO METRIC THREAD according to DIN 13-M Coarse Metric- Tolerance 6g
LEFT-HAND USE.
HSS, with chamfer, for steel with R up to 600 N/mm².
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Dimensions
mm 20x5 20x5 20x7 20x7 25x9 30x11 38x14
9353G
Each 11,30 11,30 12,10 12,10 14,10 18,60 26,10
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
Dimensions
mm 38x14 45x18 45x18 45x18 55x22 55x22
9353G
Each 29,90 41,30 41,30 41,30 61,30 61,30
ROUNDDIES
9354G
INOX
M
HSS-E
Orig. Völkel - Art. 574
Product description as Art. 9350G
ISO METRIC THREAD, according to DIN 13 – M Coarse Metric -Tolerance 6g
RIGHT-HAND USE.
HSS. Normal chamfer. For stainless steel and steel with R up to 1200 N/mm².
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Dimensions
mm 20x5 20x5 20x7 20x7 25x9 30x11 38x14
9354G
Each 11,10 11,10 11,40 11,40 16,10 23,10 36,20
Ø
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
Dimensions
mm 38x14 45x18 45x18 45x18 55x22 55x22
9354G
Each 36,20 54,60 54,60 54,60 97,20 97,20
ROUNDDIES
9357G
MF
HSS
Orig. Völkel - Art. 264-266
Product description as Art. 9350G
ISO FINE METRIC THREAD, according to DIN 13 - MF Fine Metric – Tolerance 6g
RIGHT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm².
Ø
mm
3
3,5
4
4
5
6
6
7
8
8
8
9
10
10
Pitch
mm
0,35 0,35 0,35 0,5
0,5
0,5 0,75 0,75 0,5 0,75
1
1
0,5 0,75
Dimensions
mm 20x5 20x5 20x5 20x5 20x5 20x5 20x7 25x9 25x9 25x9 25x9 25x9 30x11 30x11
9357G
Each 15,40 15,40 15,40 15,40 15,40 15,40 12,90 16,40 16,40 13,60 13,60 20,80 20,80 20,80
Ø
mm
10
10
11
12
12
12
14
14
14
15
16
16
18
18
Pitch
mm
1
1,25
1
1
1,25 1,5
1
1,25 1,5
1
1
1,5
1
1,5
Dimensions
mm 30x11 30x11 30x11 38x10 38x10 38x10 38x10 38x10 38x10 38x10 45x14 45x14 45x14 45x14
9357G
Each 15,70 15,70 23,50 20,10 20,10 19,30 26,20 22,10 22,10 35,60 35,60 27,10 32,80 27,10
Ø
mm
18
19
20
20
20
21
22
22
22
23
24
24
24
25
Pitch
mm
2
1
1
1,5
2
1
1
1,5
2
1
1
1,5
2
1
Dimensions
mm 45x14 45x14 45x14 45x14 45x14 45x14 55x16 55x16 55x16 55x16 55x16 55x16 55x16 55x16
9357G
Each 33,50 48,50 33,50 27,10 33,50 50,60 54,20 47,70 54,20 71,10 54,20 47,70 54,20 69,80
SEGUE >>>
