HAND TAPS
13
9125G
9127G
UNC
HSSG
Orig. Völkel - Art. 233 - Art. 233-3
Product description as Art. 9100G
RIGHT-HAND USE.
UNC AMERICAN THREAD according to ANSI-B.1.1 – Tolerance 2 B- (DIN 352).
3pcs set.
Thread UNC
Nr. 1 Nr. 2 Nr. 3 Nr. 4 Nr. 5 Nr. 6 Nr. 8
Threads per inch
Nr
64
56
48
40
40
32
32
Ø
mm 1,85
2,18
2,52
2,85
3,18
3,5
4,17
Overall length
mm 32
36
36
40
40
45
45
Thread length
mm 10
11
11
12
12
14
14
Shank Ø
mm 2,5
2,8
2,8
3,5
3,5
4
4,5
Shank square
mm 2,1
2,1
2,1
2,7
2,7
3
3,4
9125G
Per series 53,40 53,40 53,40 32,50 32,50 32,50 32,50
9127G
Finisher 17,80 17,80 17,80 10,90 10,90 10,90 10,90
Thread UNC
Nr. 10 Nr. 12 1/4
5/16
3/8
7/16
1/2
Threads per inch
Nr
24
24
20
18
16
14
13
Ø
mm 4,83
5,49
6,35
7,94
9,52 11,11 12,7
Overall length
mm 50
50
50
56
70
70
75
Thread length
mm 16
18
19
22
24
24
29
Shank Ø
mm 6
6
6
6
7
8
9
Shank square
mm 4,9
4,9
4,9
4,9
5,5
6,2
7
9125G
Per series 32,50 32,50 17,10 19,30 21,40 27,10 32,50
9127G
Finisher 10,90 10,90 5,70
6,42
7,12
8,98 10,90
Thread UNC
9/16
5/8
3/4
7/8
1
Threads per inch
Nr
12
11
10
9
8
Ø
mm 14,29 15,87 19,05 22,23 25,4
Overall length
mm 80
80
95
100
110
Thread length
mm 30
32
40
40
50
Shank Ø
mm 11
12
14
18
18
Shank square
mm 9
9
11
14,5
14,5
9125G
Per series 42,80 47,90 64,10 85,50 98,30
9127G
Finisher 14,30 16,10 21,40 28,50 32,80
vuoto
HANDTAPS
9130G
9132G
UNF
HSSG
Orig. Völkel - Art. 243
Product description as Art. 9100G
RIGHT-HAND USE.
UNF AMERICAN THREAD according to ANSI-B 1.1 – Tolerance 2 B – (DIN 2181).
2pcs set.
Thread UNF
Nr. 1 Nr. 2 Nr. 3 Nr. 4 Nr. 5 Nr. 6 Nr. 8
Threads per inch
Nr
72
64
56
48
44
40
36
Ø
mm 1,85
2,18
2,52
2,85
3,18
3,5
4,17
Overall length
mm 32
32
32
36
36
40
40
Thread length
mm 9
10
10
11
11
12
12
Shank Ø
mm 2,8
2,8
2,8
3,5
3,5
4,5
4,5
Shank square
mm 2,1
2,1
2,1
2,7
2,7
3,4
3,4
9130G
Per series 35,60 35,60 35,60 21,70 21,70 21,70 21,70
9132G
Finisher 17,80 17,80 17,80 10,90 10,90 10,90 10,90
Thread UNF
Nr. 10 Nr. 12 1/4
5/16
3/8
7/16
1/2
Threads per inch
Nr
32
28
28
24
24
20
20
Ø
mm 4,83
5,49
6,35
7,94
9,52 11,11 12,7
Overall length
mm 45
50
50
56
63
63
75
Thread length
mm 14
14
18
22
22
22
22
Shank Ø
mm 6
6
6
6
7
8
9
Shank square
mm 4,9
4,9
4,9
4,9
5,5
6,2
7
9130G
Per series 21,70 21,70 11,40 12,90 14,30 18,10 21,70
9132G
Finisher 10,90 10,90 5,70
6,42
7,12
8,98 10,90
Thread UNF
9/16
5/8
3/4
7/8
1
Threads per inch
Nr
18
18
16
14
12
Ø
mm 14,29 15,87 19,05 22,23 25,4
Overall length
mm 80
80
95
100
110
Thread length
mm 28
28
32
36
40
Shank Ø
mm 11
12
14
18
18
Shank square
mm 9
9
11
14,5
14,5
9130G
Per series 28,50 31,90 42,80 57,10 65,50
9132G
Finisher 14,30 16,10 21,40 28,50 32,80
vuoto
