1216 / 1410
1216
Prices in EURO - VAT not included
1216
MACHINE SHELL REAMERS
13
9010G
Orig. Dürr - Art. 289
CONICAL SHANKS FOR REAMERS ART. 9000 G – 9003 G
Manufactured according to DIN 217.
Conical reaming on the shaft 1:30.
Morse taper shank.
Rated Ø
mm
13
16
19
22
27
32
40
For reamers 9000G e
9003G
mm 25-30 32-35 36-42 45-50 52-60 65-70 75-80
Overall length
mm 250
261
298
312
359
376
396
Drive
C.M.
3
3
4
4
5
5
5
9010G
Each 148,00 161,00 192,00 213,00 312,00 380,00 480,00
vuoto
MACHINESHELLREAMERS
EXPANDING HAND REAMERS
9013
HSS
Prod. SCU
Small expansion model – DIN 859.
HSS. Hand use.
Ground, helicoidal cutting edges.
With drive board and cylindrical shank.
Ø
mm
5
6
7
8
9
10
11
12
Cutting edge length
mm 30
33
38
42
46
50
51
56
Overall length
mm 87
93
107 115 124 133 142 152
Square drive
mm 4
4,5
5,6
6,3
7,1
8
9
10
Expansion
mm 0,1
0,1
0,1
0,1
0,1
0,1 0,15 0,15
9013
Each 54,70 65,50 74,20 83,10 91,80 96,00 110,00 118,00
Ø
mm
13
14
15
16
17
18
19
20
Cutting edge length
mm 56
61
61
67
67
68
68
75
Overall length
mm 152 163 163 177 177 188 188 201
Square drive
mm 10 11,2 11,2 12,5 12,5 14
14
16
Expansion
mm 0,15 0,15 0,15 0,2
0,2
0,2
0,2
0,2
9013
Each 136,00 145,00 158,00 179,00 201,00 210,00 229,00 229,00
vuoto
EXPANDINGHANDREAMERS
9016G
HSS
Orig. Dürr - Art. 317-21
Small expansion model – DIN 859.
HSS. Hand use.
Helicoidal cutting edges.
With drive board and cylindrical shank.
The max expansion capacity is equal to 1% of the indicated Ø.
Ø
mm
6
8
10
12
13
14
15
16
Cutting edge length
mm 33
42
50
56
56
61
61
67
Overall length
mm 93
115 133 152 152 163 163 175
Square drive
mm 4,5
6,3
8
10
10 11,2 11,2 12,5
9016G
Each 95,10 99,80 116,00 132,00 162,00 157,00 163,00 195,00
Ø
mm
18
19
20
22
24
25
30
Cutting edge length
mm 68
68
75
82
85
85
94
Overall length
mm 188 188 201 215 231 231 247
Square drive
mm 14
14
16
18
20
20 22,4
9016G
Each 221,00 224,00 224,00 279,00 308,00 301,00 391,00
vuoto
Size mm 13 is running out of stock
EXPANDINGHANDREAMERS
ADJUSTABLE REAMERS
9020
Prod. SCU
With SHORT blades, parallel expansion.
Cutting edges in special steel (90 Mn Cr V – AISI 02), ground. Hand use.
With drive board and cylindrical shank.
Expansion
mm
8-9
9-10 10-11 11-12 12-13,5 13,5-15,5 15,5-18 18-21 21-24 24-27,5 27,5-31,5 31,5-37
Cutting edges length
mm 38
40
46
48
50
55
66
66
77
88
88
106
Overall length
mm 110
120
125
130
140
155
170
180
200
225
235
277
Blades
Nr
4
4
4
4
5
5
5
5
5
5
5
5
9020
Each 88,20 90,50 90,50 91,80 94,40 102,00 111,00 119,00 133,00 150,00 184,00 230,00
Expansion
mm
37-45 45-55 55-65
Cutting edges length
mm 106
130
130
Overall length
mm 290
320
350
Blades
Nr
5
6
6
9020
Each 338,00 478,00 603,00
vuoto
Spare blade for Art. 9020.
Expansion
mm
8-9
9-10 10-11 11-12 12-13,5 13,5-15,5 15,5-18 18-21 21-24 24-27,5 27,5-31,5 31,5-37
O9020
Per series 49,30 54,40 55,80 55,80 66,50 68,10 72,20 75,50 77,20 85,40 98,50 118,00
Expansion
mm
37-45 45-55 55-65
O9020
Per series 177,00 233,00 267,00
vuoto
ADJUSTABLEREAMERS
