DIN 6499-B/ISO 15488 ER/ESX COLLETS FOR CHUCKS, WIDE OPENING
1561GN
32
Product description as Art. 1561GA
Size 32.
Clamping elastic capacity 1mm. Dimensions (mm) D = 33 L = 40.
Tightening Ø
mm
2
3
4
5
6
7
8
1561GN
Each 51,60 40,30 40,30 40,30 40,30 40,30 40,30
Tightening Ø
mm
9
10
11
12
13
14
15
1561GN
Each 40,30 40,30 40,30 40,30 40,30 40,30 40,30
Tightening Ø
mm
16
17
18
19
20
1561GN
Each 40,30 40,30 40,30 40,30 40,30
vuoto
DIN6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1561GR
40
Product description as Art. 1561GA
Size 40.
Clamping elastic capacity 1mm. Dimensions (mm) D = 41 L = 46.
Tightening Ø
mm
3
4
5
6
7
8
9
1561GR
Each 69,70 52,10 52,10 52,10 52,10 52,10 52,10
Tightening Ø
mm
10
11
12
13
14
15
16
1561GR
Each 52,10 52,10 52,10 52,10 52,10 52,10 52,10
Tightening Ø
mm
17
18
19
20
21
22
23
1561GR
Each 52,10 52,10 52,10 52,10 52,10 52,10 52,10
Tightening Ø
mm
24
25
26
28
30
1561GR
Each 52,10 52,10 52,10 61,10 61,10
For Ø size mm 28 and 30 rotation’s precision to 10 µm.
vuoto
DIN6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
ASSORTMENT OF ER/ESX COLLETS FOR CHUCKS
1561GT
Prod. SCU - Orig. Fahrion
In practical case for easy access.
Size
8
11
16
20
25
32
40
Chucks included Art.
1561GA 1561GB 1561GC 1561GF 1561GL 1561GN 1561GR
min/max tightening Ø mm 1-5
1-7
1-10
2-13
2-16
3-20
4-26
Chucks included
Nr
9
13
10
12
15
18
23
1561GT
Each 440,00 562,00 407,00 495,00 626,00 783,00 1.280,00
vuoto
ASSORTMENTOFER/ESXCOLLETSFORCHUCKS
TRACTION COMPENSATED PINCERS
1562GG
1562GH
1562GL
1562GM
Code
Thread DIMENSION
range
A D1 D2 D3 L1 L2 L3
1562GG
M1-M6 7 17 11 6,3 22 20 7
1562GH
M1-M8 7 21 14 7,1 24 23 8
1562GL
M3-M10 8 26 19 10 26 24 10
1562GM
M4-M12 10 33 23 12,5 33 32 11
Prod. SCU - Orig. Fahrion
In special steel, precision manufacture according to class 2 corresponding to a rotation precision
ranging from 15 to 20 µm. Finely worked. Traction compensation. Sealing ring to keep the male
holder pivot clean. Ball sliding and drawing.
Size 16.
Tightening Ø
mm
2,24
2,5
2,8
3,15
3,5
3,55
4
1562GG
Each 201,00 206,00 206,00 201,00 206,00 201,00 206,00
Tightening Ø
mm
4,5
5
5,5
6
6,3
1562GG
Each 206,00 206,00 206,00 206,00 206,00
Sizes mm 2,24, 3,15 and 3,55 are running out of stock
vuoto
Product description as Art. 1562GG
Size 20.
Tightening Ø
mm
2,5
2,8
3,15
3,5
3,55
4
4,5
1562GH
Each 206,00 206,00 201,00 206,00 201,00 206,00 206,00
Tightening Ø
mm
5
5,5
6
6,3
7
1562GH
Each 206,00 206,00 206,00 206,00 206,00
Sizes mm 3,15 and 3,55 are running out of stock
vuoto
Product description as Art. 1562GG
Size 25.
Tightening Ø
mm
3,15
3,5
3,55
4
4,5
5
5,5
1562GL
Each 211,00 216,00 211,00 216,00 216,00 216,00 216,00
Tightening Ø
mm
6
6,3
7
8
9
10
1562GL
Each 216,00 216,00 216,00 216,00 216,00 216,00
Sizes mm 3,15 and 3,55 are running out of stock
vuoto
Product description as Art. 1562GG
Size 32.
Tightening Ø
mm
4,5
5
5,5
6
6,3
7
8
1562GM
Each 231,00 231,00 231,00 231,00 231,00 231,00 231,00
Tightening Ø
mm
9
10
11
11,2
12
12,5
1562GM
Each 231,00 231,00 231,00 231,00 231,00 231,00
vuoto
