449 / 1410
449
Prices in EURO - VAT not included
6
449
ASSORTMENTS OF ELASTIC PLIERS - ER/ESX TYPE
ASSORTMENTS OF ELASTIC PLIERS - ER/ESX TYPE
1560GZE
Prod. SCU
On support for easy access.
Size
16
20
25
32
Chucks included Art.
1560GS 1560GT 1560GV 1560GZ
min/max tightening Ø mm 1-10
2-13
2-16
3-20
Chucks included
Nr
10
12
15
18
1560GZE
Each 214,00 277,00 327,00 402,00
vuoto
ASSORTMENTSOFELASTICPLIERS -ER/ESXTYPE
DIN 6499-B/ISO 15488 ER/ESX COLLETS FOR CHUCKS, WIDE OPENING
1561GA
8
Prod. SCU - Orig. Fahrion
In special steel. High rotation precision up to 5 µm. This product allows using higher working
parameters, it gives tools longer life, saving on working costs. Treated surface, ruby balls, lapped,
with beveled edges for collets stronger clamping and chucks longer life. Particularly suitable for
use with HSC and orig. Fahrion chucks.
Size 8.
Clamping elastic capacity 0.5mm. Dimensions (mm) D = 8,5 L = 13,6.
Tightening Ø
mm
1
1,5
2
2,5
3
3,5
4
1561GA
Each 50,10 50,10 50,10 50,10 41,60 41,60 41,60
Tightening Ø
mm
4,5
5
1561GA
Each 41,60 41,60
vuoto
DIN 6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1561GB
11
Product description as Art. 1561GA
Size 11.
Clamping elastic capacity 0.5mm. Dimensions (mm) D = 11,5 L = 18.
Tightening Ø
mm
1
1,5
2
2,5
3
3,5
4
1561GB
Each 46,60 46,60 46,60 46,60 37,70 37,70 37,70
Tightening Ø
mm
4,5
5
5,5
6
6,5
7
1561GB
Each 37,70 37,70 37,70 37,70 37,70 37,70
vuoto
DIN 6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1561GC
16
Product description as Art. 1561GA
Size 16.
Clamping elastic capacity 1mm (0.5 for clamping Ø 1-1.5mm).
Dimensions (mm) D = 17 L = 27,5.
Tightening Ø
mm
1
1,5
2
2,5
3
3,5
4
1561GC
Each 45,10 45,10 45,10 45,10 35,50 60,90 35,50
Tightening Ø
mm
4,5
5
5,5
6
6,5
7
7,5
1561GC
Each 60,90 35,50 60,90 35,50 60,90 35,50 60,90
Tightening Ø
mm
8
8,5
9
9,5
10
1561GC
Each 35,50 60,90 35,50 60,90 35,50
vuoto
DIN 6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1561GF
20
Product description as Art. 1561GA
Size 20.
Clamping elastic capacity 1mm. Dimensions (mm) D = 21 L = 31,5.
Tightening Ø
mm
2
2,5
3
3,5
4
5
6
1561GF
Each 46,30 46,30 36,70 61,80 36,70 36,70 36,70
Tightening Ø
mm
7
8
9
10
11
12
13
1561GF
Each 36,70 36,70 36,70 36,70 36,70 36,70 36,70
vuoto
DIN 6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
1561GL
25
Product description as Art. 1561GA
Size 25.
Clamping elastic capacity 1mm. Dimensions (mm) D = 26 L = 34.
Tightening Ø
mm
2
2,5
3
3,5
4
5
6
1561GL
Each 48,90 48,90 37,70 62,80 37,70 37,70 37,70
Tightening Ø
mm
7
8
9
10
11
12
13
1561GL
Each 37,70 37,70 38,30 37,70 37,70 37,70 37,70
Tightening Ø
mm
14
15
16
1561GL
Each 37,70 37,70 37,70
vuoto
DIN 6499-B/ISO 15488ER/ESXCOLLETSFORCHUCKS,WIDEOPENING
