SELF-CENTRING CHUCKS
1567V
new
Set of 4 jaws in untempered steel, integral. For Art. 1567 P.
Ø
mm
125
160
200
250
315
1567V
Per series 144,00 164,00 185,00 282,00 401,00
vuoto
SELF-CENTRINGCHUCKS
1569G
Prod. SCU - Röhm
Simple guide, special spheroidal die cast body. 4-jaws very high-precision model.
With 2 jaw sets: 1 for inside use, 1 for outside use and wrench. Slipping parts hardened and
ground. Excellent vibration absorption, crown forged, balanced and hardened. In compliance with
DIN 6350 standards.
Ø
mm
100
125
160
200
250
315
Bore Ø
mm 20
32
42
55
76
103
rev/min
Nr
4500 4000 3600 3000 2500 2000
Tightening force
kN 27
31
47
55
63
69
1569G
Each 910,00 996,00 1.200,00 1.420,00 1.950,00 2.890,00
On request we supply Jaws sets for indoor, outdoor and not hardened.
vuoto
Riferimenti quote
A (Diametro)
mm 100
125
160
200
250
315
B (H6) mm
mm 70
95
125
160
200
260
C
mm 3
4
4
4
5
5
D
mm 50
56
65
73,5
82
95
E
mm 20
32
42
55
76
103
F
mm 83
108
140
176
224
286
G
mm 3xM8 3xM8 3xM10 3xM10 3xM12 3xM16
H
mm 48
52
61
69
90
130
J
mm 18
22,5
26
32,5
40
46
K
mm 8
9
10
11
12
14
Peso c.a.
Kg 2,9
4,5
8,2
14,6
25,7
44,2
SELF-CENTRINGCHUCKS
1569P
new
J
C
G
A
F
D
E
B
B1
L
H
K
Prod. SCU
Double guide, special spheroidal die cast body. 3-jaws very high-precision model.
With 2 jaw sets: 1 for inside use, 1 for outside use and wrench. Slipping parts hardened and
ground. Excellent vibration absorption, forged crown, balanced and hardened. In compliance with
DIN 6350 standards.
Ø
mm
160
200
250
315
Bore Ø
mm 42
55
76
103
rev/min
Nr
3600 3000 2500 2000
Tightening force
kN 31
37
46
55
1569P
Each 1.050,00 984,00 1.330,00 2.060,00
vuoto
A (Diametro)
mm 160
200
250
315
B
mm 74,5
83
96
111
B1
mm 79,3 87,8 99,8 115,1
C
mm 6,5
6,5
6,0
6,3
D H7
mm 125
160
200
260
E
mm 42
55
76
103
F
mm 140
176
224
286
G
mm 6xM10 6xM10 6xM12 6xM16
J
mm 25
29
34
41,3
L
mm 43,1
45
53
57
Peso c.a.
kg 10
17,5
29
50
Riferimenti quote
SELF-CENTRINGCHUCKS
1569R
new
Set of 3 internal jaws in tempered steel, integral. For Art. 1569 P.
Ø
mm
160
200
250
315
1569R
Per series 273,00 291,00 398,00 612,00
vuoto
SELF-CENTRINGCHUCKS
1569T
new
Set of 3 external jaws in tempered steel, integral. For Art. 1569 P.
Ø
mm
160
200
250
315
1569T
Per series 272,00 291,00 398,00 612,00
vuoto
SELF-CENTRINGCHUCKS
1569V
new
Set of 3 jaws in untempered steel, integral. For Art. 1569 P.
Ø
mm
160
200
250
315
1569V
Per series 205,00 235,00 297,00 474,00
vuoto
