456 / 1410
456
Prices in EURO - VAT not included
6
456
REVOLVING CENTERS
1580
60
Heavy duty, high-precision centering.
In high resistance steel, completely hardened and ground. Hardness HRc 61-63.
3 x double ball bearings. Point at 60°
Drive
C.M.
2
3
4
5
6
Rotating tip Ø
mm 18
24
25
38
50
Body Ø
mm 46
60
70
90
105
rev/min
Nr
5500 5500 5000 4000 2800
Max load
Kg 220
500
800
1500 2500
Weight
Kg 0,680 1,300 2,100 4,500 9,200
1580
Each 157,00 209,00 283,00 411,00 1.070,00
vuoto
REVOLVINGCENTERS
BULL NOSE LATHE CENTERS
1582
60
Prod. SCU
Type suitable for pipe and hollow parts lathing and grinding.
Completely in hardened and ground steel.
Self-adjusting and thrust bearings.
Point at 60°
Size
2
2A 3A
5
Drive
C.M.
2
2
3
5
Rotating cone max Ø mm 45
55
70
90
Rotating cone min Ø mm 15
20
25
32
Max axial load
Kg
80
120
150
350
1582
Each 223,00 278,00 334,00 456,00
Product running out of stock
vuoto
BULLNOSE LATHECENTERS
REVOLVING CENTERS WITH INTERCHANGEABLE INSERTS
1584E
Prod. SCU
Light. Made of hardened and ground steel.
Complete with interchangeable inserts and extractor for the inserts.
CM connection. 2. Length of rotating body only 35 mm. Total length without inserts 130 mm.
1584E
Each 277,00
vuoto
REVOLVINGCENTERSWITH INTERCHANGEABLE INSERTS
1584G
Prod. SCU - Röhm
High precision model. Housing in high-resistance steel.
Spindle in special steel, hardened and ground.
Triple-range of ball bearings and guide rollers, liquid-proof, slag-proof.
Interchangeable points at 60°, 90°, truncated and hollow cone. Conic drive, hardened and ground.
Only revolving centre without inserts.
Drive
C.M.
2
3
4
Length of rotating body
only
mm 45
48
67
Max axial load
Kg
40
130
250
1584G
Each 438,00 428,00 606,00
vuoto
REVOLVINGCENTERSWITH INTERCHANGEABLE INSERTS
1584GA
60
Point at 60° for Art. 1584 G.
For tailstock drive
C.M.
2
3
4
1584GA
Each 52,80 62,60 73,40
vuoto
1584GA
2
3
4
A
C
16
13
20
17
28
23,5
REVOLVINGCENTERSWITH INTERCHANGEABLE INSERTS
1584GC
90
Point at 90° for Art. 1584 G.
For tailstock drive
C.M.
2
3
4
1584GC
Each 71,80 71,80 85,60
vuoto
1584GC
2
3
4
A
C
16
7,5
20
9,5
28
13,5
REVOLVINGCENTERSWITH INTERCHANGEABLE INSERTS
