196 PRECISION TORQUE WRENCHES
Prices in EURO - VAT not included
3
196
803B Product description as Art. 803A
With square through drive and socket stop pin.
Size 400 550 750 850
Square drive inch 3/4 3/4 3/4 3/4
Tightening capacity Nm 80-400 110-550 150-750 250-850
Tightening capacity 60-300 80-405 110-550 185-630
Scale division 1 Nm 1 Nm 1 Nm 1 Nm
Overall length mm 715,5 953,5 1228,5 1375,5
Weight Kg 2,4 3,8 4,9 5,2
Supplier code .................... DMK 400 DMK 550 DMK 750 DMK 850
803B Each 608,00 961,00 1.100,00 1.200,00
Wrenches Art. 803 A 100 - 200 - 300 and 803 B 400 with sockets and extensions can be supplied on request in a metal case.
vuoto
Spare 1/2 square drives with disk, for torque wrenches Art. 803 A 100 - 200 - 300.
O803C Each 23,40
vuoto
Spare square connectors for wrenches Art. 803 B 400 - 550 - 750 - 850 see Art. 974 RD.
PRECISIONTORQUEWRENCHES
803E Orig. Gedore - Dremaster UK
Release type model.
Suitable for precision installations. Sturdy construction, easy to handle with ratchet movement
towards the right (is only able to move to the left by unscrewing). Can be adjusted by rotating the
ergonomic handle with safety lock, which includes visual monitoring located at the far end. An
additional quick adjustment is also possible by using round tenders, although these are not
provided. Dual component handle with soft, non-slip grip with a clear path through to the centre
providing an accurate hold and an accurate calibration process. Tolerance: ± 3% for each scale
reading. Dual scale Nm/ reading which can be selected by using the cursor, and which helps
to avoid any potential reading errors. Micrometric adjustments with Nm values.
Equipped with items certified as per DIN ISO 6789:2003.
Type II, Class A.
Size 100 200 300
Square drive inch 1/2 1/2 1/2
Tightening capacity Nm 20-100 40-200 60-300
Tightening capacity 15-75 30-150 45-220
Scale division 0,5 Nm 1 Nm 1 Nm
Overall length mm 438 529 620
Weight Kg 1,2 1,4 1,6
Supplier code .................... DMUK 100 DMUK 200 DMUK 300
803E Each 410,00 428,00 468,00
vuoto
PRECISIONTORQUEWRENCHES
PRECISION TORQUE WRENCHES WITHOUT SIZES SCALE
803G
9x12 14x18
Orig. Gedore
Model without scale. High precision tightening on pre-set torque value. ± 3% tolerance of the
scale set torque. Audible acustic signal ("click") on reaching of the set torque value, angled
movement at 3° of the rod, to allow tightening even in difficult-to access places. Handy and light
construction. Automatic reset. "FS" torque wrenches must be preset directly on the place of use
by means of suitable torque testers Art. 793 GC-D/793 GL/793 GT and fixed on the desired value
within the tightening range of the wrenches mentioned below. Bi-directional tightening. Possibility
to unscrew without changing the wrench (function available only on this model).
Supplied with test certificate as per DIN ISO 6789.
Torque wrenches Art. 803 G and 803 GP can be fixed set at the factory
on the desired value (price on request).
Size 25 50 85 200
Inserts drive mm 9x12 9x12 9x12 14x18
Tightening capacity Nm 2-25 5-50 15-85 20-200
Overall length mm 180 240 320 400
Weight Kg 0,21 0,27 0,34 0,75
Supplier code .................... 4150-25 4150-50 4150-85 4151-20
803G Each 177,00 182,00 195,00 258,00
For use with torque testers Art. 793 GC-D, heads Art. 806 GD 1/4 - 3/8 are required.
For use with torque testers Art. 793 GL, heads Art. 806 GD 3/8 - 1/2 or Art. 806 GE 3/8 - 1/2 are
required (for Art. 803 G 200 heads Art. 806 GM 1/2 or Art. 806 GP 1/2 are required.
For use with torque testers Art. 793 GT, heads Art. 806 GD 1/2" or Art. 806 GE 1/2" are requi-
red (for Art. 803 G 200 heads Art 806 GM 3/4" o Art. 806 GP 3/4" are required).
