192

ANGLE INDICATORS FOR CONTROLLED ANGLE CLAMPING

Prices in EURO - VAT not included

3

192

798GH 3

Orig. Gedore - Art. 8200-01

Professional type.

For angular values clamping. Necessary for nut orientation and final clamping.

Alloy steel goniometer, 360° graduated, with flexible arm, clamping spring and magnet for fixing

point 0°.

Max. tightening capacity Nm 390

Male drive

inch 1/2

Female drive

inch 1/2

798GH 3

Each 296,00

vuoto

ANGLE INDICATORSFORCONTROLLEDANGLECLAMPING

798GH 5

Orig. Gedore - Art. 8200-02

Product description as Art. 798GH 3

Max. tightening capacity Nm 1330

Male drive

inch 3/4

Female drive

inch 3/4

798GH 5

Each 434,00

Torque wrench max. clamping strength includes angular values.

vuoto

ANGLE INDICATORSFORCONTROLLEDANGLECLAMPING

DIRECT READING TORQUE WRENCHES

798GP 1

798GP 1A

798GP 2

Orig. Torqueleader

Model with dial to check tightening. ± 4% tolerance of the scale set torque. Special light alloy

body with rubber ergonomic handle. Double scale with readings in Nm-lbf. in./lbf. ft. For bi-

directional tightening.

Also suitable to determine torque values of already tightened bolts.

Supplied with test certificate in accordance with DIN ISO 6789.

With integrated ratchet. Supplied in synthetic material case

Art......................................

798GP 1

798GP 1A

798GP 2

Drive

inch

1/4

1/4

1/4

Tightening capacity

Nm 0,8-4

1,6-8,0

2,4-12

Tightening capacity

lbf.in

7-35

14-75

24-120

Scale division

0,1 Nm/1

lbf.in

0,25 Nm/1

lbf.in

0,5 Nm/2

lbf.in

Overall length

mm 244

244

244

Weight

Kg

0,52

0,52

0,52

Supplier code ....................

ADS 4

ADS 8

ADS 12 D

Each 531,00

531,00

531,00

vuoto

When stocks will be run out, will be shipped the same item marked Gedore.

Available on request: same wrenches with audiovideo signal when the pre-set value is reached.

DIRECTREADINGTORQUEWRENCHES

798GP 3

798GP 4

Product description as Art. 798GP 1

With integrated ratchet. Supplied in synthetic material case

Art......................................

798GP 3

798GP 4

Drive

inch

3/8

3/8

Tightening capacity

Nm 5-25

8-40

Tightening capacity

lbf.in

48-240

72-360

Scale division

1 Nm/10

lbf.in

1 Nm/10

lbf.in

Overall length

mm 244

244

Weight

Kg

0,52

0,52

Supplier code ....................

ADS 25

ADS 40

Each 531,00

531,00

vuoto

When stocks will be run out, will be shipped the same item marked Gedore.

Available on request: same wrenches with audiovideo signal when the pre-set value is reached.

DIRECTREADINGTORQUEWRENCHES

798GP 5

798GP 5A

798GP 6

Product description as Art. 798GP 1

With integrated ratchet. Supplied in plastic wallet.

Art......................................

798GP 5

798GP 5A

798GP 6

Drive

inch

1/2

1/2

1/2

Tightening capacity

Nm 16-80

32-160

40-200

Tightening capacity

lbf.ft

12-60

24-120

30-160

Scale division

2 Nm/1

lbf.ft

2,5 Nm/2

lbf.ft

5 Nm/5

lbf.ft

Overall length

mm 435

515

515

Weight

Kg

1,36

1,41

1,41

Supplier code ....................

BDS 80 E

BDS 160

BDS 200

Each 807,00

807,00

807,00

vuoto

When stocks will be run out, will be shipped the same item marked Gedore.

Available on request: same wrenches with audiovideo signal when the pre-set value is reached.

DIRECTREADINGTORQUEWRENCHES
