PRECISION TORQUE WRENCHES WITHOUT SIZES SCALE
Prices in EURO - VAT not included
3
198
803GR
803GT
9x12
SLIDING MODEL WITHOUT SCALE. High precision tightening on pre-set torque value. Over-
tightening is not possible. Automatic reset. Automatic disconnection through angled movement at
110° of the head. Heads in stainless steel microfusion, body in special aluminium alloy,
ergonomic handgrip. "STB" torque wrenches must be preset directly on the place of use by
means of suitable torque testers Art. 793 GC-D-L-T and fixed on the desired value within the
tightening range of the wrenches mentioned below. Ideal for controlled clamping of joints of
hydraulic and air compressed plants.
Right operation.
Supplied with test certificate as per DIN ISO 6789.
± 4% tolerance of the set scale torque.
With end fitting frontal connection 9x12mm.
Art......................................
803GR
803GT
Tightening capacity
Nm
7-35
20-70
Overall length
mm
250
350
Weight
Kg
0,50
1
Supplier code ....................
STB 35 G
STB 70 G
Each
599,00
616,00
In case of use with torque tester Art. 793 GC-D, connections Art. 806 GD 1/4 - 3/8 or Art. 806 GE 1/4 - 3/8 are necessary.
In case of use with torque tester Art. 793 GL, connections Art. 806 GD 3/8 - 1/2 or Art. 806 GE 3/8 - 1/2 are necessary.
n case of use with torque tester Art. 793 GT, connectionsi Art. 806 GD 1/2" or Art. 806 GE 1/2" are necessary.
Product running out of stock
vuoto
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE
803GV
803GZ
16
Product description as Art. 803GT
± 4% tolerance of the set scale torque.
Straight connection with Ø 16mm male pin.
Art......................................
803GV
803GZ
Tightening capacity
Nm
7-35
20-70
Overall length
mm
225
365
Weight
Kg
0,50
1
Supplier code ....................
STB 35
STB 70
Each
572,00
593,00
In case of use with torque tester Art. 793 GC-D, connections Art. 809 GR are necessary.
In case of use with torque tester Art. 793 GL, connections Art. 809 GL-R-S are necessary.
In case of use with torque tester Art. 793 GT, connections Art. 809 G are necessary.
Product running out of stock
vuoto
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE
PRECISION TORQUE WRENCHES WITHOUT SIZES SCALE, WITH SIGNAL OUTPUT SISTEM
804GA
9x12
Orig. Torqueleader
SWITCH TYPE WITHOUT SCALE WITH ELECTRONIC SWITCH (Sw), that allows an external
device to check if the pre-set torque value has been reached and to count how many times this
value has been applied. The wrench is connected to the monitoring device by means of a cable and
can be interfaced with computers, switches etc. This system allows for the automated monitoring of
the application process of tightening in any line production.
Other features of the wrenches similar to Art. 803 GA-B-D-E-F.
The wrenches are supplied with a switch Art. 794 GHA and a cable of the length of approx. 5 m Art.
794 GHB.
Size
2
10
25
65
135
Tightening capacity
Nm 0,4-2
1-10
5-25
10-65
27-135
Tightening capacity
lbf.in/ft3,5-18
9-89
4-18
7-48
18-100
Overall length
mm 133
133
415
452
558
Weight
Kg
0,13
0,15
0,75
1,09
1,68
Supplier code
TBN 2 G Sw TBN 10 G Sw TBN 25 G Sw TBN 65 G Sw TBN 135 G Sw
804GA
Each 884,00
897,00
923,00
976,00
1.040,00
When stocks will be run out, will be shipped the same item marked Gedore.
On request, the spanners Art. 803 GF to 803 GPE can be supplied with an electrical switch (Sw).
On request the spanners Art. 804 GA can be supplied pre-calibrated to the desired value for an additional charge.
