Catalogo SICUTOOL 2017 - Versione inglese con prezzi

194 / 1410

194 PRECISION TORQUE WRENCHES
Prices in EURO - VAT not included
3
194
800GA Orig. Carolus
Release type model.
Suitable for precision installations. Handy left and right side ratchets, which can be reversed
through the framework. Can be adjusted by rotating the ergonomic plastic handle with a safety
lock for final positioning.
Tolerance: ± 3% for each scale reading. Double micrometer scale Nm/ with figures which can
be viewed via a magnifying glass and which can be finely tuned and adjusted by using the handle.
Equipped with items certified as per DIN ISO 6789.
Size 25 70 100 200 300
Square drive inch 1/4 3/8 1/2 1/2 1/2
Tightening capacity Nm 5-25 14-70 20-100 40-200 60-300
Tightening capacity 3,7-18 10-52 15-75 30-150 45-220
Scale division 0,1 Nm 0,20 Nm 0,5 Nm 1 Nm 1 Nm
Overall length mm 285 350 395 485 575
Supplier code .................... 4900.025 6900.070 5900.100 5900.200 5900.300
800GA Each 206,00 210,00 210,00 210,00 219,00
vuoto
PRECISIONTORQUEWRENCHES
800GB Release type model.
Suitable for precision installations. Handy left and right side ratchets, which can pass through the
framework. Can be adjusted by rotating the ergonomic plastic handle with a safety lock for final
positioning.
Tolerance: ± 3% for each scale reading. Double micrometer scale Nm/ with figures which can
be viewed via a magnifying glass and which can be finely tuned and adjusted by using the handle.
Equipped with items certified as per DIN ISO 6789.
Size 400 550
Square drive inch 3/4 3/4
Tightening capacity Nm 80-400 110-550
Tightening capacity 60-300 80-405
Scale division 1 Nm 1 Nm
Overall length mm 685 955
Supplier code .................... 8900.400 8900.550
800GB Each 363,00 568,00
vuoto
Square fitting parts for torque wrenches in accordance with Art. 800 GA - B.
Art. O800 GC 1/4 - 3/8 - 1/2: with disk.
Art. O800 GC 3/4: without disk.
Square drive inch 1/4 3/8 1/2 3/4
O800GC Each 12,80 11,10 11,10 11,60
vuoto
PRECISIONTORQUEWRENCHES
801GR
801GS
Orig. Gedore
Click type, suitable to precise tightening. Handy construction with right/left ratchet mechanism,
with reverse square drive. Adjustment obtained by rotating the ergonomically shaped nylon
handgrip, safety lock at the extremity.
± 3% tolerance of the scale set torque. Double scale with graduation Nm on handle below a
window with a magnifying-glass effect for a more precise reading.
Supplied with test certificate as per DIN ISO 6789.
Art...................................... 801GR 801GS
Square drive inch 1/4 1/4
Tightening capacity Nm 1-5 5-25
Tightening capacity 0,75-3,7 3,7-18
Scale division 0,025 Nm 0,1 Nm
Overall length mm 224 285
Weight Kg 0,30 0,45
Supplier code .................... 4549-00 4549-02
Each 261,00 279,00
vuoto
PRECISIONTORQUEWRENCHES
801GT Orig. Gedore - Art. 4549-05
Product description as Art. 801GR
Square drive inch 3/8
Tightening capacity Nm 10-50
Tightening capacity 7,5-37
Scale division 0,25 Nm
Overall length mm 335
Weight Kg 0,54
801GT Each 287,00
vuoto
