Catalogo SICUTOOL 2017 - Versione inglese con prezzi

197 / 1410

197
PRECISION TORQUE WRENCHES WITHOUT SIZES SCALE
3
Prices in EURO - VAT not included 197
803GA
803GB
9x12
Orig. Torqueleader
Model without scale. High precision tightening on pre-set torque value. Long-lasting serial
tightening. Automatic reset. Automatic disconnection through angled movement at 20° of the rod.
"TBN" torque wrenches must be preset directly on the place of use by means of suitable torque
testers Art. 793 GA-B-C or 793 GT and fixed on the desired value within the tightening range of
the wrenches mentioned below. Bi-directional tightening.
Supplied with test certificate as per DIN ISO 6789.
± 6% tolerance of the scale set torque. Type with 9x12mm end fittings frontal connection.
Art...................................... 803GA 803GB
Tightening capacity Nm 0,4-2 1-10
Tightening capacity 3,5-18 9-89
Overall length mm 133 133
Weight Kg 0,13 0,15
Supplier code..................... TBN 2 G TBN 10 G
Each 294,00 306,00
vuoto
When stocks will be run out, will be shipped the same item marked Gedore.
For use with torque testers Art. 793 GA-B-C, heads Art. 806 GD 1/4 - 3/8 or Art. 806 GE 1/4 - 3/8 are required.
For use with torque testers Art. 793 GT, heads Art. 806 GD 1/4" or Art. 806 GE 1/4" are required.
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE
803GC
803GD
803GE
803GF
9x12 14x18
Model without scale. High precision tightening on pre-set torque value. Long-lasting serial
tightening. Automatic reset. Automatic disconnection through angled movement at 20° of the rod.
"TBN" torque wrenches must be preset directly on the place of use by means of suitable torque
testers Art. 793 GD (only for Art. 803 GC), 793 GL-T and fixed on the desired value within the
tightening range of the wrenches mentioned below. Bi-directional tightening.
Supplied with test certificate as per DIN ISO 6789.
Tolerance: ± 4% for each capacity reading.
Type with frontal connection of inserts.
Art...................................... 803GC 803GD 803GE 803GF
Inserts drive mm 9x12 9x12 9x12 14x18
Tightening capacity Nm 5-25 10-65 27-135 40-200
Tightening capacity 4-18 7-48 18-100 29-147
Overall length mm 265 302 408 520
Weight Kg 0,40 0,75 1,03 1,4
Supplier code..................... TBN 25 G TBN 65 G TBN 135 G TBN 200 G
Each 332,00 385,00 429,00 568,00
vuoto
When stocks will be run out, will be shipped the same item marked Gedore.
When using with calibrating device Art. 793 GD, use inserts Art. 806 GD 1/4 - 3/8 or Art. 806 GE 1/4 - 3/8.
When using with calibrating devices Art. 793 GL, use inserts Art. 806 GD 3/8 - 1/2 or Art. 806 GE 3/8 - 1/2.
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE
803GL
803GM
803GP
803GPE
16
Model without scale. High precision tightening on pre-set torque value. Long-lasting serial
tightening. Automatic reset. Automatic disconnection through angled movement at 20° of the rod.
"TBN" torque wrenches must be preset directly on the place of use by means of suitable torque
testers Art. 793 GD (only for Art. 803 GL), 793 GL-T and fixed on the desired value within the
tightening range of the wrenches mentioned below. Bi-directional tightening.
Supplied with test certificate as per DIN ISO 6789.
± 4% tolerance of the scale set torque. Type with straight end fitting with male pin Ø 16mm.
Art...................................... 803GL 803GM 803GP 803GPE
Tightening capacity Nm 5-25 10-65 27-135 40-200
Tightening capacity 4-18 7-48 18-100 29-147
Overall length mm 265 302 408 520
Weight Kg 0,40 0,75 1,03 1,4
Supplier code..................... TBN 25 TBN 65 TBN 135 TBN 200
Each 319,00 370,00 412,00 540,00
vuoto
When stocks will be run out, will be shipped the same item marked Gedore.
When using with calibrating device Art. 793 GD, use inserts Art. 809 GR 3/8.
When using with calibration devices Art. 793 GL, use inserts Art. 809 GL-R-S.
When using with calibrating device Art. 793 GT, use inserts Art. 809
PRECISIONTORQUEWRENCHESWITHOUTSIZESSCALE
