200 TORQUE WRENCHES WITH FEMALE DRIVE
Prices in EURO - VAT not included
3
200
805GC
805GD
805GE
14x18
Product description as Art. 804GS
With end fitting frontal connection.
Art...................................... 805GC 805GD 805GE
Inserts drive mm 14x18 14x18 14x18
Tightening capacity Nm 40-200 60-300 80-400
Tightening capacity 30-150 45-220 60-300
Scale division 1 Nm 1 Nm 1 Nm
Overall length mm 471 562 649
Weight Kg 0,9 1,2 1,6
Supplier code .................... 4201-01 4300-01 4301-01
Each 255,00 291,00 433,00
vuoto
TORQUEWRENCHESWITHFEMALEDRIVE
805GF
9x12
Orig. Gedore - Dremaster SE
Release type model.
Suitable for precision installations. Easy to handle: Can be adjusted by rotating the ergonomic
handle with safety lock, which includes visual monitoring located at the far end. An additional
quick adjustment is also possible by using round tenders, although these are not provided. Dual
component handle with soft, non-slip grip with a clear path through to the centre providing an
accurate hold and an accurate calibration process. Tolerance: ± 3% for each scale reading. Dual
scale Nm reading which can be selected by using the cursor, and which helps to avoid any
potential reading errors. Micrometric adjustments with Nm values.
Equipped with items certified as per DIN ISO 6789:2003.
Type II, Class A.
Type with frontal connection of inserts.
Size 100 150
Inserts drive mm 9x12 9x12
Tightening capacity Nm 20-100 30-150
Tightening capacity 15-75 22-110
Scale division 0,5 Nm 1 Nm
Overall length mm 398,5 489,5
Weight Kg 0,8 1,0
Supplier code .................... DMSE 100 DMSE 150
805GF Each 246,00 276,00
vuoto
TORQUEWRENCHESWITHFEMALEDRIVE
805GH
14x18
Product description as Art. 805GF
Type with frontal connection of inserts.
Size 200 300 400
Inserts drive mm 14x18 14x18 14x18
Tightening capacity Nm 40-200 60-300 80-400
Tightening capacity 30-150 45-220 60-300
Scale division 1 Nm 1 Nm 1 Nm
Overall length mm 499,5 590,5 677,5
Weight Kg 1,1 1,3 2,0
Supplier code .................... DMSE 200 DMSE 300 DMSE 400
805GH Each 282,00 324,00 480,00
vuoto
TORQUEWRENCHESWITHFEMALEDRIVE
805GL
805GP
9x12
Orig. Gedore
Click type. Light alloy body. Inside components in alloyed steel. ± 3% tolerance of the scale set
torque. Double scale Nm/lbf on handle. Adjustment by means of the jointed socket built-in in the
handle. Audible acustic signal ("click") on reaching preset torque value. For controlled bi-
directional tightening.
Supplied with test certificate as per DIN ISO 6789.
With end fitting frontal connection.
Art...................................... 805GL 805GP
Inserts drive mm 9x12 9x12
Tightening capacity Nm 8-40 25-120
Tightening capacity 70-350 -
Tightening capacity - 18-90
Scale division 5 Nm/50 5 Nm/5
Overall length mm 365 490
Weight Kg 0,95 1,25
Supplier code .................... 8480-01 8481-01
Each 594,00 655,00
vuoto
TORQUEWRENCHESWITHFEMALEDRIVE
805GR
14x18
Orig. Gedore - Art. 8482-01
Product description as Art. 805GL
With end fitting frontal connection.
Inserts drive mm 14x18
Tightening capacity Nm 80-400
Tightening capacity -
Tightening capacity 60-300
Scale division 5 Nm/5
Overall length mm 650
Weight Kg 1,7
805GR Each 822,00
