Catalogo SICUTOOL 2017 - Versione inglese con prezzi

191 / 1410

191
ASSORTED SET OF TOOLS WITH TORQUE WRENCH
3
Prices in EURO - VAT not included 191
796GM
796GN
Orig. Gedore - Art. 8563-30
Product description as Art. 796G 1
The set consists of:
1 x 795 G 25 torque wrench
1 x socket ratchet
8 x 22-24-27-30-32-36-41-46mm hexagonal
sockets
2 x 200-400mm extensions
Square drive inch 3/4
Weight Kg 13,6
796GM Each 2.180,00
vuoto
Orig. Gedore - Art. 8568-30
Product description as Art. 796G 1
The set consists of:
1 x 795 G 27 torque wrench
1 x socket ratchet
8 x 22-24-27-30-32-36-41-46mm hexagonal
sockets
2 x 200-400mm extensions
Square drive inch 3/4
Weight Kg 13,6
796GN Each 2.210,00
vuoto
ASSORTEDSETOFTOOLSWITH TORQUEWRENCH
796GP
796GQ
Orig. Gedore - Art. 8571-03
Product description as Art. 796G 1
The set consists of:
1 x 795 G 33 torque wrench
1 socket ratchet
6 x 30-32-36-41-46-50mm hexagonal sockets
2 x 200-400mm extensions
Square drive inch 3/4
Weight Kg 16,8
796GP Each 2.510,00
vuoto
Orig. Gedore - Art. 8576-03
Product description as Art. 796G 1
The set consists of:
1 795 G 35 torque wrench
1 socket ratchet
6 x 30-32-36-41-46-50mm hexagonal sockets
2 x 200-400mm extensions
Square drive inch 3/4
Weight Kg 16,8
796GQ Each 2.540,00
vuoto
ASSORTEDSETOFTOOLSWITH TORQUEWRENCH
796GR
796GS
Orig. Gedore - Art. 8564-03
Product description as Art. 796G 1
The set consists of:
1 x 795 G 37 torque wrench
1 x socket ratchet
8 x 36-41-46-50-55-60-65-70mm hexagonal
sockets
2 x 200-400mm extensions
Square drive inch 1
Weight Kg 30,4
796GR Each 4.980,00
vuoto
Orig. Gedore - Art. 8569-03
Product description as Art. 796G 1
The set consists of:
1 x 795 G 39 torque wrench
1 x socket ratchet
8 x 36-41-46-50-55-60-65-70mm hexagonal
sockets
2 x 200-400mm extensions
Square drive inch 1
Weight Kg 30,4
796GS Each 5.060,00
vuoto
ASSORTEDSETOFTOOLSWITH TORQUEWRENCH
TORQUE WRENCHES FOR ANGLE CONTROLLED TIGHTENING
798GD
798GE
Orig. Gedore
Click type. To perform dynamometric and angle- controlled tightenings. Allow bolt serial tightening
and safety control tightening. ± 3% tolerance of the scale set torque. Normally used also for
normal torque tightening control. The torque wrench and the angle indicator are locked together
on the main pin. The reference position of the angle indicator is determined by means of a sliding
magnetic arm. Supplied with test certificate in accordance with DIN ISO 6789.
Standard equipment:
1 torque wrench for angle controlled tightening
1 x ratchet head 1/2 for clockwise tightening
1 x 125mm extension
1 x 250mm extension
Supplied in metal case.
Art...................................... 798GD 798GE
Drive inch 1/2 1/2
Tightening capacity Nm 20-120 40-200
Tightening capacity 15-90 30-150
Scale division 5 Nm/5 5 Nm/5
Overall length mm 485 575
Supplier code..................... 8261-03 8273-03
Each 909,00 947,00
vuoto
TORQUEWRENCHESFORANGLECONTROLLEDTIGHTENING
ANGLE INDICATORS FOR CONTROLLED ANGLE CLAMPING
798GH 2
Orig. Gedore - Art. 8200-11
Cheap type.
For angular values clamping. Necessary for nut orientation and final clamping.
360° graduated goniometer with magnet and flexible arm for fixing point 0°.
Clamping strength max. 390 Nm.
Male drive inch 1/2
Female drive inch 1/2
798GH 2 Each 182,00
vuoto
ANGLE INDICATORSFORCONTROLLEDANGLECLAMPING
