TORQUE WRENCHES WITH FEMALE DRIVE
3
Prices in EURO - VAT not included 199
TORQUE WRENCHES WITH FEMALE DRIVE
804GH
804GL
9x12
Orig. Torqueleader
Dividing model providing real accuracy for repeating processes with a set value.
Robust construction which provides long performance life when installing bulk items. Tolerance: ±
6% for each scale reading.
Automatic disconnection with 20° angular rod body movement. Automatic reset feature.
Micrometer Nm scale providing a clear view of the values.
Ergonomic adjustment by rotating the handle complete with safety lock, positioned at the far end.
Can be used with both left and right handed operation.
Equipped with items certified as per DIN ISO 6789.
Type with frontal connection of inserts.
Art...................................... 804GH 804GL
Inserts drive mm 9x12 9x12
Tightening capacity Nm 1-5 2-10
Scale division 0,025 Nm 0,05 Nm
Overall length mm 230 230
Weight Kg 0,29 0,3
Supplier code..................... ATB 5 G ATB 10 G
Each 380,00 380,00
vuoto
When stocks will be run out, will be shipped the same item marked Gedore.
TORQUEWRENCHESWITH FEMALEDRIVE
804GP
9x12
Orig. Carolus
Release type model.
Suitable for precision installations. Easy to handle: Tolerance: ± 3% for each scale reading. Dual
micrometer scale Nm with handle and values which can be viewed by using a magnifying
glass for easy reading. Can be adjusted by rotating the ergonomic plastic handle with a safety
lock for final positioning.
For use with left and right handed operation.
Equipped with items certified as per DIN ISO 6789.
Type with frontal connection of inserts.
Size 50 150
Inserts drive mm 9x12 9x12
Tightening capacity Nm 10-50 30-150
Tightening capacity 8-37 20-110
Scale division 0,25 Nm 1 Nm
Overall length mm 324 460,5
Supplier code..................... 6912.050 5912.150
804GP Each 187,00 199,00
Product running out of stock
vuoto
TORQUEWRENCHESWITH FEMALEDRIVE
804GR
14x18
Product description as Art. 804GP
Type with frontal connection of inserts.
Size 200 300
Inserts drive mm 14x18 14x18
Tightening capacity Nm 40-200 60-300
Tightening capacity 30-150 45-220
Scale division 1 Nm 1 Nm
Overall length mm 470,5 561,5
Supplier code..................... 5918.200 5918.300
804GR Each 199,00 277,00
Product running out of stock
vuoto
TORQUEWRENCHESWITH FEMALEDRIVE
804GS
804GT
805GA
805GB
9x12
Orig. Gedore
Click type. Handy construction. ± 3% tolerance of the scale set torque.
Double scale with graduation Nm on handle below a window with a magnifying-glass effect
that makes reading easier.
Adjustment obtained by rotating the ergonomically shaped nylon handgrip, safety lock at the
extremity. For controlled bi-directional tightening.
Supplied with test certificate as per DIN ISO 6789.
With end fitting frontal connection.
Art...................................... 804GS 804GT 805GA 805GB
Inserts drive mm 9x12 9x12 9x12 9x12
Tightening capacity Nm 5-25 10-50 20-100 30-150
Tightening capacity 3,7-18 7,5-37 15-75 22-110
Scale division 0,1 Nm 0,25 Nm 0,5 Nm 1 Nm
Overall length mm 274 324 370 461
Weight Kg 0,3 0,45 0,6 0,8
Supplier code..................... 4101-02 4101-05 4100-01 4200-02
Each 202,00 212,00 223,00 249,00
vuoto
