INSERTS HOLDER FOR MILLING WITH MECHANICAL FIXING
13
9845L
new
Type for 45° MILLING AND COPYING with hole shank and internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
3
4
5
Ø D
mm 40
50
63
80
100
Overall lenght H
mm 40
48
48
50
54
Drive Ø d
mm 16
22
22
27
32
Size P
mm 6
6
6
6
6
Insert number
Nr
3
4
5
6
6
For inserts Art. (Cod. id.)
9848G
(SE..1204)
9848G
(SE..1204)
9848G
(SE..1204)
9848G
(SE..1204)
9848G
(SE..1204)
9845L
Each 190,00
208,00
223,00
256,00
288,00
vuoto
Spare screws TORX T 20 for Art. 9845 L 1.
OV9845L 1
Each 6,54
vuoto
Spare screws TORX T 20 for Art. 9845 L 2 a 5.
OV9845L 2
Each 6,54
INSERTSHOLDERFORMILLINGWITHMECHANICALFIXING
9845M
new
Product description as Art. 9845L
Size
1
2
3
4
Ø D
mm 50
63
80
100
Overall lenght H
mm 48
48
50
55
Drive Ø d
mm 22
22
27
32
Size P
mm 6
6
6
6
Insert number
Nr
4
5
6
6
For inserts Art. (Cod. id.)
9848H
(SE..13T3)
9848H
(SE..13T3)
9848H
(SE..13T3)
9848H
(SE..13T3)
9845M
Each 217,00
244,00
266,00
340,00
vuoto
Spare screws TORX T 15 for Art. 9845 M 1 a 4.
OV9845M
Each 4,28
INSERTSHOLDERFORMILLINGWITHMECHANICALFIXING
9845P
new
Type for STRAIGHT SOULDER MILLING with threaded shank and internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
Ø D
mm
20
25
Lungh. L
mm
30
35
Drive Ø
M
10
12
Size P
mm
10
10
Shank Ø d
mm
10,5
12,5
Insert number
Nr
3
4
For inserts Art. (Cod. id.)
9848L 0,5-0,8-1,2
(AP..1003)
9848L 0,5-0,8-1,2
(AP..1003)
9845P
Each
179,00
194,00
vuoto
Spare screws TORX T 8 for Art. 9845 P 1-2.
OV9845P
Each 4,46
INSERTSHOLDERFORMILLINGWITHMECHANICALFIXING
9845R
new
Type for SHOULDER MILLING with threaded shank and internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
Ø D
mm
32
42
Lungh. L
mm
48
48
Misura H
mm
15
15
Radius R
mm
3
3
Insert number
Nr
2
3
For inserts Art. (Cod. id.)
9848R
(VC..220530)
9848R
(VC..220530)
9845R
Each
276,00
330,00
For spare screws see Art. OV9845 G.
INSERTSHOLDERFORMILLINGWITHMECHANICALFIXING
9845T
new
Type for SHOULDER MILLING with cylindrical shank and crossarms, internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
3
Ø D
mm
25
28
32
Lungh. L1
mm
44
44
50
Overall length L
mm
100
100
110
Drive Ø d
mm
25
25
32
Insert number
Nr
2
3
3
For inserts Art. (Cod. id.)
9848P 0,8-1,6-3,2
(AP..1604)
9848P 0,8-1,6-3,2
(AP..1604)
9848P 0,8-1,6-3,2
(AP..1604)
9845T
Each
106,00
123,00
127,00
vuoto
Spare screws TORX T 15 for Art. 9845 T 1-2.
OV9845T 1
Each 3,94
vuoto
Spare screws TORX T 15 for Art. 9845 T 3/9845 V 1 a 3/9845 Z 1-2/9846 A 1 a 8/9846 E 1-4-7/
9846 F 1 a 6.
OV9845T 3
Each 6,54
