1298 / 1410
1298
Prices in EURO - VAT not included
1298
INSERTS HOLDER FOR TURNING WITH MECHANICAL FIXING
13
9809
Steel, threaded screw fastening suitable for screw threads. Without bits, with screws.
Right-hand, external use. ISO THREAD.
Square stem side
mm
20
25
Pitch
mm 1,5
1,5
Overall length
mm 125
150
9809
Each 88,80 99,80
For inserts see Art. 9833 L.
Underplates and spare screws can be supplied on request.
vuoto
INSERTSHOLDERFOR TURNINGWITHMECHANICALFIXING
9809E
Steel, threaded screw fastening suitable for rotating and copying. Without bits, with screws.
Right-hand, internal use.
Flat/round stem Ø
mm
8
10
12
16
Cutting angle
degrees 95
95
95
95
Overall length
mm 125
140
160
180
Min. bore Ø
mm 11
15
17
22
9809E
Each 77,10 77,10 77,10 92,10
For inserts see Art. 9833 P.
Spare screws can be supplied on request.
vuoto
INSERTSHOLDERFOR TURNINGWITHMECHANICALFIXING
9809F
Assortment of 8 mechanical tool attachments.
Comprises:
1 pcs. per type Art. 9809 E 8 - 10 - 12 - 16
3 pcs. Art. 9833 P 8
1 pcs. Art. 9833 P 16
In cardboard box.
9809F
Each 362,82
vuoto
INSERTSHOLDERFOR TURNINGWITHMECHANICALFIXING
9810
Made from treated steel. Disk fixing system with threaded screw, suitable for turning and copying.
Without bits, with screws.
Right-hand, internal use.
Flat/round stem Ø
mm
20
25
Cutting angle
degrees 92
92
Overall length
mm 250
300
Head width and length
mm 13x35 17x40
Min. bore Ø
mm 27
34
9810
Each 249,00 298,00
For inserts see Art. 9834 - 9836 - 9838.
Subplates and spare screws can be supplied on request.
vuoto
INSERTSHOLDERFOR TURNINGWITHMECHANICALFIXING
9812
Steel, threaded screw fastening suitable for screw threads. Without bits, with screws.
Right-hand, internal use. ISO THREAD.
Flat/round stem Ø
mm
20
25
Pitch
mm 1,5
1,5
Overall length
mm 170
300
Min. bore Ø
mm 24
30
9812
Each 97,60 113,00
For inserts see Art. 9840.
Underplates and spare screws can be supplied on request.
