1301 / 1410
1301
Prices in EURO - VAT not included
1301
INSERTS HOLDER FOR MILLING WITH MECHANICAL FIXING
13
Size
10
11
12
13
14
15
16
17
Ø D
mm 25
32
32
35
35
35
40
42
Lungh. L
mm 35
43
43
43
43
43
43
43
Drive Ø
M 12
16
16
16
16
16
16
16
Shank Ø d
mm 12,5
17
17
17
17
17
17
17
Radius R
mm 5
5
5
5
5
5
5
5
Insert number
Nr
3
3
4
3
4
5
4
5
For inserts Art. (Cod. id.)
9848A 10
(RD..1003)
9848A 10
(RD..1003)
9848A 10
(RD..1003)
9848A 10
(RD..1003)
9848A 10
(RD..1003)
9848A 10
(RD..1003)
9848A 10
(RD..1003)
9848A 10
(RD..1003)
9845E
Each 162,00
171,00
197,00
171,00
199,00
226,00
199,00
228,00
vuoto
Spare screws TORX T 7 for Art. 9845 E 1 a 7 / 9846 E 2-3-5-6.
OV9845E 1
Each 7,20
vuoto
Spare screws TORX T 15 for Art. 9845 E 8.
OV9845E 8
Each 7,20
vuoto
Spare screws TORX T 15 for Art. 9845 E 9 a 17.
OV9845E 9
Each 7,20
vuoto
INSERTSHOLDER FORMILLINGWITHMECHANICALFIXING
9845F
new
Type for MILLING AND COPYING with cylindrical shank and internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
3
4
5
6
Ø D
mm 10
12
16
20
25
32
Lungh. L1
mm 35
50
53
61
70
80
Overall length L
mm 150
160
175
190
190
210
Drive Ø d
mm 12
12
16
20
25
32
Radius R
mm 5
6
8
10
12,5
16
Insert number
Nr
1
1
1
1
1
1
For inserts Art. (Cod. id.)
9848E 10
(WPR10..)
9848E 12
(WPR12..)
9848E 16
(WPR16..)
9848E 20
(WPR20..)
9848E 25
(WPR25..)
9848E 32
(WPR32..)
9845F
Each 175,00 175,00 194,00 222,00 259,00 290,00
vuoto
Spare screws TORX T 15 for Art. 9845 F 1.
OV9845F 1
Each 27,40
Spare screws TORX T 20 for Art. 9845 F 2.
OV9845F 2
Each 27,40
Spare screws TORX T 20 for Art. 9845 F 3.
OV9845F 3
Each 36,70
Spare screws TORX T 20 for Art. 9845 F 4.
OV9845F 4
Each 34,50
Spare screws TORX T 30 for Art. 9845 F 5.
OV9845F 5
Each 37,70
Spare screws TORX T 30 for Art. 9845 F 6.
OV9845F 6
Each 37,70
INSERTSHOLDER FORMILLINGWITHMECHANICALFIXING
9845G
new
Type for MILLING AND COPYING with hole shank and internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
3
4
5
Ø D
mm 50
52
63
66
80
Overall lenght H
mm 50
50
50
50
50
Drive Ø d
mm 22
22
27
27
27
Size P
mm 8
8
8
8
8
Insert number
Nr
4
4
5
5
6
For inserts Art. (Cod. id.)
9848A 16
(RD..1604)
9848A 16
(RD..1604)
9848A 16
(RD..1604)
9848A 16
(RD..1604)
9848A 16
(RD..1604)
9845G
Each 232,00
232,00
278,00
281,00
324,00
vuoto
Spare screws TORX T 20 for Art. 9845 G 1 a 5 / 9845 R 1-2 / 9846 B 1 a 4.
OV9845G
Each 5,42
vuoto
INSERTSHOLDER FORMILLINGWITHMECHANICALFIXING
9845H
new
Type for 43° MILLING AND COPYING with hole shank and internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
3
Ø D
mm 50
63
80
Overall length L
mm 40
40
50
Drive Ø d
mm 22
22
27
Size P
mm 4,5
4,5
4,5
Insert number
Nr
4
5
5
For inserts Art. (Cod. id.)
9848F
(OD..0605)
9848F
(OD..0605)
9848F
(OD..0605)
9845H
Each 230,00
254,00
289,00
vuoto
Spare screws TORX T 20 for Art. 9845 H 1 a 3.
OV9845H
Each 6,92
vuoto
INSERTSHOLDER FORMILLINGWITHMECHANICALFIXING
