1300 / 1410
1300
Prices in EURO - VAT not included
1300
INSERTS FOR TURNING WITH MECHANICAL FIXING
13
9834
9836
9838
HARTMETALL
TIN
HARD METAL, TIN-coated. Universal quality.
Exceptional hardness. Maximum shock and abrasion-proof.
For tool bit holder Art. 9810 x 20 and 25mm.
TRIANGULAR SHAPE (TPUN)
For fine removal – radius 0.4.
Dimensions: 15.8x9.52x3.18mm.
9834
Each 12,50
Product description as Art. 9834
TRIANGULAR SHAPE (TPUN)
For medium removal – radius 0.8.
Dimensions: 15.1x9.52x3.18mm.
9836
Each 12,50
Product description as Art. 9834
TRIANGULAR SHAPE (TPUN)
For thick removal – radius 1.2.
Dimensions: 14.5x9.52x3.18mm.
9838
Each 12,50
INSERTSFOR TURNINGWITHMECHANICALFIXING
9840
HARTMETALL
TIN
HARD METAL, TIN coated. Universal quality.
Exceptional hardness. Maximum resistance to impact and abrasion.
Includes mounting hole for screw.
TRIANGULAR SHAPE (16 IR 150 ISO 134), for internal threads PITCH 1.5.
For tool bit holders Art. 9812 x 20 and 25mm.
9840
Each 14,20
Other pitches can be supplied on request. Minimum quantity 120 pcs. per pitch.
vuoto
INSERTSFOR TURNINGWITHMECHANICALFIXING
TOOLS FOR EXTERNAL CUTTING
9845A
Prod. SCU
Made from CHROME-VANADIUM steel.
BLADE HOLDER BODY with fixing screws.
Shank height
mm
20
25
Dimensions
mm 100x44x41 h 110x49x48 h
For insert holder blades
Art.
9845B 1
9845B 2
9845A
Each 59,10
72,60
vuoto
TOOLSFOREXTERNALCUTTING
9845B
Product description as Art. 9845A
TOOLHOLDER BLADES
Size
1
2
Dimensions
mm 109x25,75 h 150x31,75 h
For base
Art.
9845A 20 9845A 25
For inserts
Art.
9845C 1
9845C 2
9845B
Each 45,10
45,10
TOOLSFOREXTERNALCUTTING
9845C
In hard metal.
INSERTS
Size
1
2
Thickness at the cutting edge mm 3
4
For insert holder blades
Art.
9845B 1
9845B 2
9845C
Each 9,34
10,90
vuoto
TOOLSFOREXTERNALCUTTING
INSERTS HOLDER FOR MILLING WITH MECHANICAL FIXING
9845E
new
Prod. SCU
Type for MILLING AND COPYING with threaded shank and internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
3
4
5
6
7
8
9
Ø D
mm 15
16
16
20
20
25
32
20
25
Lungh. L
mm 23
23
23
30
30
35
43
30
35
Drive Ø
M
8
8
8
10
10
12
16
10
12
Shank Ø d
mm 8,5
8,5
8,5
10,5
10,5
12,5
17
10,5
12,5
Radius R
mm 3,5
3,5
3,5
3,5
3,5
3,5
3,5
5
5
Insert number
Nr
2
2
3
3
4
5
5
2
2
For inserts Art. (Cod. id.)
9848A 7
(RD..0702)
9848A 7
(RD..0702)
9848A 7
(RD..0702)
9848A 7
(RD..0702)
9848A 7
(RD..0702)
9848A 7
(RD..0702)
9848A 7
(RD..0702)
9848A 10
(RD..1003)
9848A 10
(RD..1003)
9845E
Each 133,00
133,00
157,00
160,00
187,00
216,00
224,00
133,00
145,00
SEGUE >>>
