INSERTS HOLDER FOR TURNING WITH MECHANICAL FIXING
13
INSERTS HOLDER FOR TURNING WITH MECHANICAL FIXING
9800
Prod. SCU
Made from treated steel, pin fixing system, suitable for turning and copying.
Excellent tool bit fixing, steady housing and preservation of chip breaker position. Without bits,
with screws.
Right-hand, external use.
Square stem side
mm
20
25
Cutting angle
degrees 90
90
Overall length
mm 125
150
Head width and length
mm 25x22 32x22
9800
Each 153,00 172,00
For inserts see Art. 9820 – 9822 – 9824.
vuoto
Spare support plate (for size 20 and 25mm), for Art.9800.
O9800A
Each 14,40
vuoto
Spare plate pin (for size 20 and 25mm), for Art. 9800.
O9800B
Each 11,80
vuoto
INSERTSHOLDER FORTURNINGWITHMECHANICALFIXING
9802
Product description as Art. 9800
Right-hand, external use.
Square stem side
mm
20
25
Cutting angle
degrees 90
90
Overall length
mm 125
150
Head width and length
mm 25x22 32x22
9802
Each 153,00 172,00
For inserts see Art. 9820 – 9822 – 9824.
vuoto
Spare support plate (for size 20 and 25mm), for Art.9802.
O9802A
Each 14,40
vuoto
Spare plate pin (for size 20 and 25mm), for Art. 9802.
O9802B
Each 11,80
vuoto
INSERTSHOLDER FORTURNINGWITHMECHANICALFIXING
9804
Product description as Art. 9800
Right-hand, external use.
Square stem side
mm
20
25
Cutting angle
degrees 75
75
Overall length
mm 125
150
Head width and length
mm 17x28 22x28
9804
Each 153,00 172,00
For inserts see Art. 9820 – 9822 – 9824.
vuoto
Spare support plate (for size 20 and 25mm), for Art.9804.
O9804A
Each 14,40
vuoto
Spare plate pin (for size 20 and 25mm), for Art. 9804.
O9804B
Each 11,80
vuoto
INSERTSHOLDER FORTURNINGWITHMECHANICALFIXING
9806
Product description as Art. 9800
Right-hand, external use.
Square stem side
mm
20
25
Cutting angle
degrees 45
45
Overall length
mm 125
150
Head width and length
mm 22x25 28x32
9806
Each 153,00 172,00
For inserts see Art. 9828 – 9830.
vuoto
Spare support plate (for size 20 and 25mm), for Art.9806.
O9806A
Each 19,20
vuoto
Spare plate pin (for size 20 and 25mm), for Art. 9806.
O9806B
Each 10,20
vuoto
INSERTSHOLDER FORTURNINGWITHMECHANICALFIXING
9808
Product description as Art. 9800
Right-hand, external use.
Square stem side
mm
20
25
Cutting angle
degrees 95
95
Overall length
mm 125
150
9808
Each 67,20 75,90
For inserts see Art. 9832.
Brackets and spare screws can be supplied on request.
