INSERTS FOR TURNING WITH MECHANICAL FIXING
13
INSERTS FOR TURNING WITH MECHANICAL FIXING
9820
9822
9824
HARTMETALL
TIN
Prod. SCU
HARD METAL, TIN-coated. Universal quality.
Exceptional hardness. Maximum shock and abrasion-proof.
With fixing hole for central pin.
For tool bit holder Art. 9800 - 9802 - 9804 for 20 and 25 mm.
TRIANGULAR SHAPE (TNMG)
For fine removal – radius 0.4.
Dimensions: 15.8x9.52x4.76mm.
9820
Each 14,10
vuoto
Product description as Art. 9820
TRIANGULAR SHAPE (TNMG)
For medium removal – radius 0.8.
Dimensions 15.4x9.52x4.76mm.
9822
Each 13,90
vuoto
Product description as Art. 9820
TRIANGULAR SHAPE (TNMG)
For thick removal – radius 1.2.
Dimensions 14.7x9.52x4.76mm.
9824
Each 13,90
vuoto
INSERTSFORTURNINGWITHMECHANICALFIXING
9828
9830
HARTMETALL
TIN
HARD METAL, TIN-coated. Universal quality.
Exceptional hardness. Maximum shock and abrasion-proof.
With fixing hole for central pin.
For tool bit holder Art. 9806 x 20 and 25mm.
SQUARE SHAPE (SNMG)
For medium removal – radius 0.8.
Dimensions 12.7x4.76mm.
9828
Each 15,60
vuoto
Product description as Art. 9828
SQUARE SHAPE (SNMG)
For thick removal – radius 1.2.
Dimensions 12.7x4.76mm.
9830
Each 15,60
vuoto
INSERTSFORTURNINGWITHMECHANICALFIXING
9832
HARTMETALL
TIN
HARD METAL, TIN coated. Universal quality.
Exceptional hardness. Maximum resistance to impact and abrasion.
Includes mounting hole for screw.
RHOMBOID SHAPE (CNMG)
For tool bit holders Art. 9808 x 20 and 25mm.
For medium removal - radius 0.8.
Dimensions 12.7x4.76mm.
9832
Each 12,30
vuoto
INSERTSFORTURNINGWITHMECHANICALFIXING
9833L
HARTMETALL
TIN
HARD METAL, TIN coated. Universal quality.
Exceptional hardness. Maximum resistance to impact and abrasion.
Includes mounting hole for screw.
TRIANGULAR SHAPE (16 ER 150 ISO 134), for external threads at 60°.
For tool bit holders Art. 9809 x 20 and 25mm.
Pitch
mm
1
1.25
1.5
1.75
2
2.5
3
9833L
Each 14,20 14,20 14,20 14,20 14,20 14,20 14,20
vuoto
INSERTSFORTURNINGWITHMECHANICALFIXING
9833P
HARTMETALL
TIN
Product description as Art. 9833L
RHOMBOID SHAPE (CCMT)
For tool bit holders Art. 9809 E x 8 - 10 - 12 - 16.
Size
mm
8
16
For toolholders
Art.
9809 E 8-10-12 9809 E 16
Radius
mm
0,4
0,4
CCMT shape
060204N
09T304N
9833P
Each
9,34
11,40
vuoto
INSERTSFORTURNINGWITHMECHANICALFIXING
