INSERTS HOLDER FOR CHAMFERING AND COUNTERSINKING WITH MECHANICAL FIXING
13
INSERTS HOLDER FOR CHAMFERING AND COUNTERSINKING WITH MECHANICAL FIXING
9846E
new
Prod. SCU
Type for Type for BEVELS and FLARES with cylindrical shank and crossarms.
WITHOUT INSERTS, with screws.
Size
1
2
3
4
5
6
7
Ø min D1
mm 6
1,8
6
12,5
5,4
15,8
20
Ø max D2
mm 32
15,5
19,5
32,5
16
26
35
Lungh. H
mm 39
20
35
39
20
35
39
Overall length L
mm 95
70
90
95
70
90
95
Drive Ø d
mm 20
12
20
25
12
20
25
Angle K°
degree
s
30
45
45
45
60
60
60
Insert number
Nr
2
1
2
2
1
2
2
For inserts Art. (Cod. id.)
9848VB
(TC..16T3)
9848VA
(TC..1102)
9848VA
(TC..1102)
9848VB
(TC..16T3)
9848VA
(TC..1102)
9848VA
(TC..1102)
9848VB
(TC..16T3)
9846E
Each 133,00 71,70 90,10 127,00 71,70 95,70 133,00
For spare screws see Art. 9845 E OV OV9845 1 and T 3.
vuoto
INSERTSHOLDERFORCHAMFERINGANDCOUNTERSINKINGWITHMECHANICALFIXING
9846F
new
Type for Type for BEVELS and FLARES with cylindrical shank and crossarms.
WITHOUT INSERTS, with screws.
Size
1
2
3
4
5
6
Ø min D1
mm 12
16
30
12
16
30
Ø max D2
mm 23,7
28,8
42,3
23,7
28,8
42,3
Lungh. L1
mm 25
35
35
20
42
40
Overall length L
mm 100
100
100
200
200
200
Drive Ø d
mm 20
20
25
20
20
25
Insert number
Nr
1
2
3
1
2
3
For inserts Art. (Cod. id.)
9848Z
(SC..09T3)
9848Z
(SC..09T3)
9848Z
(SC..09T3)
9848Z
(SC..09T3)
9848Z
(SC..09T3)
9848Z
(SC..09T3)
9846F
Each 85,90
106,00 137,00 115,00 134,00 164,00
For spare screws see Art. OV 9845 T 3.
vuoto
INSERTSHOLDERFORCHAMFERINGANDCOUNTERSINKINGWITHMECHANICALFIXING
INSERTS FOR MILLING WITH MECHANICAL FIXING
9848A
new
HARTMETALL
TiAIN
Prod. SCU
In carbide, PVD-TiAlN coating (CH 6920). Universal quality also suitable for machining stainless
steel and titanium alloys. With mounting hole for central screw.
Shape: round. Cutting angle: 15°.
Ø
mm
7
10
16
Thickness
mm
2,38
3,18
4,76
For toolholders mills
Art.
9845E 1 to 7 9845E 8 to 17 9845G 1 to 5
ISO identity card
RDHW0702MOT RDHW1003MOT RDHW1604MOT
9848A
Each
12,10
12,10
16,10
vuoto
INSERTSFORMILLINGWITHMECHANICALFIXING
9848E
new
HARTMETALL
TiAIN
Product description as Art. 9848A
Shape: half-round
Ø
mm
10
12
16
20
25
32
Height
mm 9,5
11,9
13,9
15,9
21,5
25,9
Thickness
mm 2,5
2,5
3
3
4
5
For toolholders mills
Art.
9845F 1 9845F 2 9845F 3 9845F 4 9845F 5 9845F 6
ISO identity card
WPRSN10 WPRSN12 WPRSN16 WPRSN20 WPRSN25 WPRSN32
9848E
Each 41,80
44,50
48,30
59,30
89,70
99,30
vuoto
INSERTSFORMILLINGWITHMECHANICALFIXING
9848F
new
HARTMETALL
TiAIN
Product description as Art. 9848A
Shape: octagonal. Cutting angle: 15°.
Width
mm
15,8
Lato
mm
6
Thickness
mm
5,56
Radius
mm
0,8
For toolholders mills
Art.
9845H 1 to 3
ISO identity card
ODHW060508TN
9848F
Each
19,60
vuoto
INSERTSFORMILLINGWITHMECHANICALFIXING
9848G
new
HARTMETALL
TiAIN
Product description as Art. 9848A
Shape: diamond. Cutting angle: 20°.
Lato
mm
12,7
Chamfer
mm
2,8
Thickness
mm
4,76
For toolholders mills
Art.
9845L 1 to 5
ISO identity card
SEHT1204AFTN
9848G
Each
12,70
vuoto
INSERTSFORMILLINGWITHMECHANICALFIXING
