INSERTS HOLDER FOR MILLING WITH MECHANICAL FIXING
13
9845V
new
Type for SHOULDER MILLING with cylindrical shank and internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
3
Ø D
mm
25
32
32
Lungh. L1
mm
60
60
60
Overall length L
mm
180
180
180
Drive Ø d
mm
20
25
32
Insert number
Nr
2
3
3
For inserts Art. (Cod. id.)
9848P 0,8-1,6-3,2
(AP..1604)
9848P 0,8-1,6-3,2
(AP..1604)
9848P 0,8-1,6-3,2
(AP..1604)
9845V
Each
143,00
170,00
170,00
For spare screws see Art. OV9845 T 3.
vuoto
INSERTSHOLDER FORMILLINGWITHMECHANICALFIXING
9845Z
new
Type for SHOULDER MILLING with conical shank and internally cooled.
WITHOUT INSERTS, with screws.
Size
1
2
Ø D
mm
32
40
Lungh. L1
mm
40
48
Overall length L
mm
125
157
Drive
CM
3
4
Insert number
Nr
3
4
For inserts Art. (Cod. id.)
9848P 0,8-1,6-3,2
(AP..1604)
9848P 0,8-1,6-3,2
(AP..1604)
9845Z
Each
144,00
187,00
For spare screws see Art. OV9845 T 3.
vuoto
INSERTSHOLDER FORMILLINGWITHMECHANICALFIXING
9846A
new
Type for SHOULDER MILLING with hole shank and internally cooled.
(Size 7 and 8 without internal cooling).
WITHOUT INSERTS, with screws.
Size
1
2
3
4
Ø D
mm
40
50
63
63
Overall length L
mm
40
40
40
40
Drive Ø d
mm
16
22
22
22
Insert number
Nr
4
5
5
6
For inserts Art. (Cod. id.)
9848P 0,8-1,6-
3,2 (AP..1604)
9848P 0,8-1,6-
3,2 (AP..1604)
9848P 0,8-1,6-
3,2 (AP..1604)
9848P 0,8-1,6-
3,2 (AP..1604)
9846A
Each
160,00
167,00
181,00
190,00
Size
5
6
7
8
Ø D
mm
80
100
125
160
Overall length L
mm
50
50
63
63
Drive Ø d
mm
27
32
40
40
Insert number
Nr
6
7
8
10
For inserts Art. (Cod. id.)
9848P 0,8-1,6-
3,2 (AP..1604)
9848P 0,8-1,6-
3,2 (AP..1604)
9848P 0,8-1,6-
3,2 (AP..1604)
9848P 0,8-1,6-
3,2 (AP..1604)
9846A
Each
227,00
274,00
359,00
507,00
For spare screws see Art. OV9845 T 3.
vuoto
INSERTSHOLDER FORMILLINGWITHMECHANICALFIXING
9846B
new
Product description as Art. 9846A
Size
1
2
3
4
Ø D
mm 42
52
66
80
Lungh. L
mm 57
57
57
57
Drive Ø d
mm 16
22
27
27
Misura H
mm 15
15
15
15
Insert number
Nr
3
3
4
4
For inserts Art. (Cod. id.)
9848R
(VC..220530)
9848R
(VC..220530)
9848R
(VC..220530)
9848R
(VC..220530)
9846B
Each 293,00
296,00
316,00
344,00
For spare screws see Art. OV9845 G.
vuoto
