1292 / 1410
1292
Prices in EURO - VAT not included
1292
TOOL HOLDERS FOR INSIDE USE
13
9749G
Product description as Art. 9748G
Shanks for tool holder Art. 9748 G.
Size
10
13
20
28
32
Length x shaft Ø
mm 165x10 245x13 325x20 385x28 450x32
9749G
Each 21,70 28,10 38,10 64,90 76,40
vuoto
TOOLHOLDERSFOR INSIDEUSE
9750G
HSS-E
Product description as Art. 9748G
HSS blades for roughing for shanks Art. 9749 G.
Size
10
13
20
28
32
For bores by Ø min
mm 14
22
30
44
54
9750G
Each 42,60 61,20 99,20 263,00 275,00
vuoto
TOOLHOLDERSFOR INSIDEUSE
9751G
HSS-E
Product description as Art. 9748G
HSS-E blades for finishing for shanks Art. 9749 G.
Size
10
13
20
28
32
For bores by Ø min
mm 14
22
30
44
54
9751G
Each 42,60 61,20 99,20 263,00 275,00
vuoto
TOOLHOLDERSFOR INSIDEUSE
9752G
55
HSS-E
Product description as Art. 9748G
HSS-E blades for 55° Whitworth thread for shanks Art. 9749 G.
Size
10
13
20
28
32
For bores by Ø min
mm 14
22
30
44
54
9752G
Each 42,60 61,20 99,20 263,00 275,00
vuoto
TOOLHOLDERSFOR INSIDEUSE
9753G
60
HSS-E
Product description as Art. 9748G
HSS-E blades for 60° metric thread for shanks Art. 9749 G.
Size
10
13
20
28
32
For bores by Ø min
mm 14
22
30
44
54
9753G
Each 42,60 61,20 99,20 263,00 275,00
vuoto
TOOLHOLDERSFOR INSIDEUSE
9754G
HSS-E
Product description as Art. 9748G
HSS-E blades for internal slots for shanks Art. 9749 G.
Size
10
13
20
28
32
For bores by Ø min
mm 14
22
30
44
54
Blades thickness for grooves mm 3
4
6
9
10
9754G
Each 42,60 61,20 99,20 263,00 275,00
vuoto
TOOLHOLDERSFOR INSIDEUSE
TAPPING HOLDERS
9758G
Prod. SCU
The adjustable head with shock absorber effect avoids cutting edge breaking during threading
process.
Possibility to adjust (right/left-hand) the threading angle. Uniform threading over all HSS blade
length.
Tool holder only without blade.
Size
1
2
3
Drive section
mm 22x10 29x13 32x25
Overall length
mm 140
170
220
9758G
Each 212,00 234,00 328,00
Size 3 is running out of stock
vuoto
TAPPINGHOLDERS
9759G
55
HSS
Product description as Art. 9758G
Blades for 55° Whitworth threads, for Art. 9758 G.
Size
1
2
3
9759G
Each 73,50 73,60 107,00
Size 3 is running out of stock
vuoto
TAPPINGHOLDERS
9760G
HSS
60
Product description as Art. 9758G
Blades for 60° Metric threads, for Art. 9758 G.
Size
1
2
3
9760G
Each 73,50 73,60 107,00
Size 3 is running out of stock
vuoto
TAPPINGHOLDERS
