1183 / 1410
1183
Prices in EURO - VAT not included
1183
SOLID CARBIDE END MILLS
13
8798L
HARTMETALL
High-performance. Hard micrograin solid carbide.
For SEMI-FINISHING, 45° three flutes. Right-hand cutting. Central tang drive.
Cylindrical shank.
Ø
mm
6
8
10
12
16
20
Overall length
mm 50
60
70
75
85
100
Cutting edge length
mm 16
20
22
27
30
38
Drive Ø
mm 6
8
10
12
16
20
8798L
Each 35,90 55,30 77,80 104,00 209,00 281,00
vuoto
SOLIDCARBIDEENDMILLS
8798T
HARTMETALL
High-performance. Hard micrograin solid carbide and HSC 883 surface coating for dry/high speed
use.
With chip breaker, fine pitch, 30° flutes. Right-hand cutting. Two central tang drives.
Cylindrical shank.
Ø
mm
6
8
10
12
14
16
18
20
Overall length
mm 50
60
70
75
85
85
100 100
Cutting edge length
mm 20
22
25
27
27
30
40
40
Drive Ø
mm 6
8
10
12
14
16
18
20
8798T
Each 41,60 59,40 82,70 112,00 159,00 180,00 270,00 328,00
vuoto
SOLIDCARBIDEENDMILLS
TUNGSTEN CARBIDE SOLID END MILLS FOR ALLUMINIUM
8799
HARTMETALL
Prod. SCU
Micrograin solid carbide.
30° single flute. Right-hand cutting. For milling aluminium and aluminium alloys.
Cylindrical shank.
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 40
50
50
50
60
70
75
Cutting edge length
mm 10
15
15
20
22
25
35
Drive Ø
mm 3
4
5
6
8
10
12
8799
Each 17,70 24,90 27,40 29,50 46,90 70,10 96,10
vuoto
TUNGSTENCARBIDESOLIDENDMILLSFORALLUMINIUM
8799A
HARTMETALL
Orig. Hartner - Art. 84914
Micrograin solid carbide, high-yield.
Long series DIN 6527 L.
Type 2 45 ° helical cutting edges. Right cutting. front tooth in the middle.
Cylindrical shank DIN 6535 HB.
Ø
mm
3
4
5
6
8
10 12 16 20
Overall length
mm 57 57 57 57 63 72 83 92 104
Cutting edge length
mm 7
8
10 10 16 19 22 26 32
Drive Ø
mm 6
6
6
6
8
10 12 16 20
8799A
Each 27,40 27,40 27,40 27,40 31,10 52,60 77,10 128,00 197,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSFORALLUMINIUM
TUNGSTEN CARBIDE SOLID END MILLS WITH FIRE COATING
8799C
HARTMETALL
FIRE
Orig. Hartner - Art. 84901
Special type with differential helix, for maximum performance in roughing and finishing materials
with hardness up to HRC 54. It allows a significant reduction in vibration, better chip flow, less
power consumption, reducing the noise level, high degree of finish of the machined surface,
without a trace of self-generating chatter. Longer life, higher speeds and feeds.
With special FIRE coating for maximum protection of the tool to cracking, maximum resistance to
heat and humidity, which increase the life and performance. Micro-grain carbide type DK 460 UF
high plasticity for a greater flexibility in processing and therefore less chance of breakage.
Very fine surface finish and dimensional precision.
Long series DIN 6527 L. Type N with 4 helical cutting edges to 35°/38°. Cutting right. Front tooth in
the middle.
Cylindrical shank DIN 6535 HA.
Ø
mm
4
5
6
8
10 12 16 20 25
Overall length
mm 57 57 57 63 72 83 92 104 121
Cutting edge length
mm 11 13 13 19 22 26 32 38 45
Drive Ø
mm 6
6
6
8
10 12 16 20 25
8799C
Each 20,80 20,80 25,80 36,50 54,70 69,80 122,00 189,00 298,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITH FIRECOATING
8799D
HARTMETALL
FIRE
Orig. Hartner - Art. 84902
Product description as Art. 8799C
Long series DIN 6527 L. Type N with 4 helical cutting edges to 35°/38°. Cutting right. Front tooth
in the middle.
Cylindrical shank DIN 6535 HB.
Ø
mm
4
5
6
8
10 12 16 20 25
Overall length
mm 57 57 57 63 72 83 92 104 121
Cutting edge length
mm 11 13 13 19 22 26 32 38 45
Drive Ø
mm 6
6
6
8
10 12 16 20 25
8799D
Each 22,80 22,80 27,90 38,50 56,70 71,90 127,00 193,00 306,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITH FIRECOATING
