1179 / 1410
1179
Prices in EURO - VAT not included
1179
DIVERGENT ANGLE CUTTERS
13
DIVERGENT ANGLE CUTTERS
8794D
HSS-E-5%
Prod. SCU
Divergent taper. DIN 1833 A – UNI 3911 A. HSS-E 5% CO.
Weldon shank. Cutting tolerance J16.
45° angle.
Ø
mm
16
20
25
32
Thickness 45°
mm 4
5
6,3
8
Overall length
mm 60
63
67
71
Drive Ø
mm 12
12
16
16
Teeth
Nr
6
6
8
10
8794D
Each 50,10 69,50 78,10 93,90
vuoto
DIVERGENTANGLECUTTERS
8794E
HSS-E-5%
Product description as Art. 8794D
60° angle.
Ø
mm
16
20
25
32
Thickness 60°
mm 6,3
8
10
12,5
Overall length
mm 60
63
67
71
Drive Ø
mm 12
12
16
16
Teeth
Nr
6
6
8
10
8794E
Each 50,10 69,50 78,10 93,90
vuoto
DIVERGENTANGLECUTTERS
CONVERGENT ANGLE CUTTERS
8794L
HSS-E-5%
Prod. SCU
Convergent taper. DIN 1833 B – UNI 3911 B. HSS-E 5% CO.
Weldon shank. Cutting tolerance J16.
45° angle.
Ø
mm
16
20
25
32
Thickness 45°
mm 4
5
6,3
8
Overall length
mm 60
63
67
71
Drive Ø
mm 12
12
16
16
Teeth
Nr
6
6
8
10
8794L
Each 50,10 69,50 78,10 93,90
vuoto
CONVERGENTANGLECUTTERS
8794M
HSS-E-5%
Product description as Art. 8794L
60° angle.
Ø
mm
16
20
25
32
Thickness 60°
mm 6,3
8
10
12,5
Overall length
mm 60
63
67
71
Drive Ø
mm 12
12
16
16
Teeth
Nr
6
6
8
10
8794M
Each 50,10 69,50 78,10 93,90
vuoto
CONVERGENTANGLECUTTERS
RADIUS MILLING CUTTERS
8794R
HSS-E-5%
Prod. SCU
Concave radius. HSS-E 5% CO.
Weldon shank. Cutting tolerance h11.
Radius R
mm
1
1,5
2
2,5
3
4
5
Head max Ø
mm 7
8
12
13
16
18
20
Overall length
mm 60
60
60
60
60
65
65
Drive Ø
mm 10
10
10
10
12
12
16
Teeth
Nr
4
4
4
4
4
4
4
8794R
Each 63,40 63,40 63,40 63,40 63,40 72,10 82,90
Radius R
mm
6
8
10
12
14
16
20
Head max Ø
mm 25
29
34
39
43
52
60
Overall length
mm 67
72
90
90
95
95
112
Drive Ø
mm 16
16
25
25
25
25
25
Teeth
Nr
4
4
5
5
5
5
6
8794R
Each 91,50 108,00 135,00 170,00 248,00 361,00 603,00
vuoto
RADIUSMILLINGCUTTERS
