1181 / 1410
1181
Prices in EURO - VAT not included
1181
SOLID CARBIDE END MILLS
13
8795L
HARTMETALL
Short series. Micrograin solid carbide.
30° two flutes. Right-hand cutting.
Central tang drive. Cylindrical shank. For slots, splines, etc.
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 60
60
70
100
100
100
100
Cutting edge length
mm 30
30
35
40
40
45
45
Drive Ø
mm 3
4
5
6
8
10
12
8795L
Each 16,50 19,80 27,10 38,10 55,80 79,10 105,00
Ø
mm
14
16
18
20
Overall length
mm 100
100
150
150
Cutting edge length
mm 45
45
50
55
Drive Ø
mm 14
16
18
20
8795L
Each 133,00 169,00 299,00 353,00
vuoto
SOLIDCARBIDEENDMILLS
8795R
HARTMETALL
Short series. Micrograin solid carbide.
30° two flutes. Right-hand cutting. Round head.
Cylindrical shank. For slots, splines, etc.
Ø
mm
2
3
4
5
6
8
10
Overall length
mm 40
40
50
50
50
60
70
Cutting edge length
mm 6
8
10
12
12
20
22
Drive Ø
mm 3
3
4
5
6
8
10
8795R
Each 18,20 14,20 18,40 20,10 24,90 38,10 58,90
Ø
mm
12
14
16
18
20
Overall length
mm 75
85
85
100
100
Cutting edge length
mm 25
30
30
38
40
Drive Ø
mm 12
14
16
18
20
8795R
Each 87,40 114,00 166,00 225,00 284,00
vuoto
SOLIDCARBIDEENDMILLS
8796
HARTMETALL
Short series. Micrograin solid carbide.
30° two flutes. Right-hand cutting.
Central tang drive. Cylindrical shank. For slots, splines and for cutting out.
Ø
mm
2
2,5
3
3,5
4
4,5
5
Overall length
mm 40
40
40
40
50
50
50
Cutting edge length
mm 5
7
12
12
16
16
20
Drive Ø
mm 3
3
3
3,5
4
4,5
5
8796
Each 15,20 13,50 11,90 13,50 15,90 17,10 17,10
Ø
mm
5,5
6
7
8
9
10
12
Overall length
mm 50
50
60
60
70
70
75
Cutting edge length
mm 20
20
22
22
22
25
27
Drive Ø
mm 5,5
6
7
8
9
10
12
8796
Each 20,20 21,10 28,80 32,40 45,10 49,70 71,90
Ø
mm
13
14
15
16
18
20
Overall length
mm 75
85
85
85
100
100
Cutting edge length
mm 27
30
30
30
40
40
Drive Ø
mm 13
14
15
16
18
20
8796
Each 79,10 97,10 128,00 139,00 187,00 234,00
vuoto
SOLIDCARBIDEENDMILLS
8796L
HARTMETALL
Long series. Micrograin solid carbide.
30° two flutes. Right-hand cutting.
Central tang drive. Cylindrical shank. For slots, splines and for cutting out.
Ø
mm
3
4
5
6
8
10
12
Overall length
mm 60
60
70
100
100
100
100
Cutting edge length
mm 30
30
35
40
40
45
45
Drive Ø
mm 3
4
5
6
8
10
12
8796L
Each 16,50 19,80 27,10 38,10 55,80 79,10 105,00
Ø
mm
14
16
18
20
Overall length
mm 100
100
150
150
Cutting edge length
mm 45
45
50
55
Drive Ø
mm 14
16
18
20
8796L
Each 133,00 169,00 299,00 353,00
vuoto
SOLIDCARBIDEENDMILLS
8796R
HARTMETALL
Short series. Micrograin solid carbide.
30° two flutes. Right-hand cutting. Round head.
Cylindrical shank. For slots, splines and for cutting out.
Ø
mm
2
3
4
5
6
8
10
Overall length
mm 40
40
50
50
50
60
70
Cutting edge length
mm 5
12
16
20
20
22
25
Drive Ø
mm 3
3
4
5
6
8
10
8796R
Each 18,20 14,20 18,40 20,10 24,90 38,10 58,90
Ø
mm
12
14
16
18
20
Overall length
mm 75
85
85
100
100
Cutting edge length
mm 27
30
30
40
40
Drive Ø
mm 12
14
16
18
20
8796R
Each 87,40 114,00 166,00 226,00 284,00
vuoto
SOLIDCARBIDEENDMILLS
