1187 / 1410
1187
Prices in EURO - VAT not included
1187
COUNTERSINKS
13
8812G
90
HSS
TIN
Product description as Art. 8810G
HSS, TIN coated.
Countersink max Ø
mm
4,3
5
5,3 5,8
6
6,3
7
7,3
8
8,3 9,4
10 10,4 11,5 12,4
Countersink min Ø
mm 1,3 1,5 1,5 1,5 1,5 1,5 1,8 1,8
2
2
2,2 2,5 2,5 2,8 2,8
Drive Ø
mm 4
4
4
5
5
5
6
6
6
6
6
6
6
8
8
Overall length
mm 40
40
40
45
45
45
50
50
50
50
50
50
50
56
56
8812G
Each 24,20 24,20 25,50 25,90 24,40 24,40 27,60 28,20 27,60 27,80 33,90 32,90 33,30 35,50 35,50
Countersink max Ø
mm
13,4 14,4 15 16,5 19 20,5 23
25
26
28
30
31
40
Countersink min Ø
mm 2,9
2
3,2 3,2 3,5 3,5 3,8 3,8 3,8
4
4,2 4,2
10
Drive Ø
mm 8
8
10
10
10
10
10
10
10
12
12
12
12
Overall length
mm 56
60
60
60
63
63
67
67
67
71
71
71
75
8812G
Each 40,20 43,80 41,50 42,70 59,80 59,80 77,20 80,60 106,00 112,00 113,00 110,00 218,00
On request also available with TiAlN coating.
vuoto
COUNTERSINKS
8813G
90
HSS
TiCN
Product description as Art. 8810G
HSS, TiCN (Titanium carbo-nitride) coated. For heat-treted steel, aluminium and aluminium
alloys.
Countersink max Ø
mm
6,3 8,3 10,4 12,4 15 16,5 20,5 25 31
Countersink min Ø
mm 1,5
2
2,5 2,8 3,2 3,2 3,5 3,8 4,2
Drive Ø
mm 5
6
6
8
10 10 10 10 12
Overall length
mm 45 50 50 56 60 60 63 67 71
8813G
Each 26,20 30,40 36,40 38,60 45,10 46,30 64,90 87,10 118,00
vuoto
COUNTERSINKS
8814G
INOX
90
HSS-E
Product description as Art. 8810G
In COBALT HSS-E. For high-resistance steel and stainless steel.
Countersink max Ø
mm
5,3
6,3
8
8,3
9,4
10
10,4
Countersink min Ø
mm 1,5
1,5
2
2
2,2
2,5
2,5
Drive Ø
mm 4
5
6
6
6
6
6
Overall length
mm 40
45
50
50
50
50
50
8814G
Each 17,90 17,50 19,50 19,80 23,90 23,20 23,90
Countersink max Ø
mm
12,4
15
16,5
20,5
25
31
40
Countersink min Ø
mm 2,8
3,2
3,2
3,5
3,8
4,2
10
Drive Ø
mm 8
10
10
10
10
12
12
Overall length
mm 56
60
60
63
67
71
75
8814G
Each 25,30 29,20 31,20 43,10 59,30 89,10 162,00
vuoto
COUNTERSINKS
8815G
90
HSS-E
Orig. Dürr - Art. 217-21
With ground flutes.
For countersinking holes. Vibration-free.
90° HEAD TAPER - DIN 335. Cylindrical shank.
COBALT HSS-E. For very high resistance steel, such as TITANIUM and its alloys, INCONEL and
similar materials.
Countersink max Ø
mm
10,4
12,4
16,5
20,5
25
31
Countersink min Ø
mm 4
4
4,5
5
5,5
6
Drive Ø
mm 6
8
10
10
10
12
Overall length
mm 50
56
60
63
67
71
Cutting edges
Nr
4
5
5
5
5
5
8815G
Each 70,10 76,40 93,10 130,00 183,00 239,00
vuoto
COUNTERSINKS
8816G
90
HARTMETALL
Orig. Dürr - Art. 217-33
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER – DIN 335. Cylindrical shank.
In SOLID CARBIDE. For steel and materials difficult to chip, cast iron, aluminium-silicium alloys
and stainless steel.
Countersink max Ø
mm
6
6,3
8
8,3
10
10,4
11,5
Countersink min Ø
mm 2
2
2
2
2,5
2,5
2,8
Drive Ø
mm 5
5
6
6
8
8
8
Overall length
mm 40
40
45
45
46
46
56
8816G
Each 172,00 182,00 174,00 184,00 162,00 162,00 172,00
Countersink max Ø
mm
12,4
15
16,5
20,5
25
31
Countersink min Ø
mm 2,8
3,2
3,2
3,5
3,8
4,2
Drive Ø
mm 8
10
10
10
10
12
Overall length
mm 56
60
60
63
67
71
8816G
Each 164,00 209,00 209,00 249,00 287,00 433,00
vuoto
COUNTERSINKS
