1186 / 1410
1186
Prices in EURO - VAT not included
1186
COUNTERSINKS
13
8802G
60
HSS
TIN
Orig. Dürr - Art. 216-31
Product description as Art. 8800G
HSS, TIN coated.
Countersink max Ø
mm
6,3
8
10
12,5
16
20
25
Countersink min Ø
mm 1,6
2
2,5
3,2
4
5
6,3
Drive Ø
mm 5
6
6
8
10
10
10
Overall length
mm 45
50
50
56
63
67
71
8802G
Each 25,60 27,60 33,50 38,10 42,90 60,40 81,10
On request also available with TiAlN coating.
vuoto
COUNTERSINKS
8804G
60
HSS
Orig. Dürr - Art. 216-61
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
60° HEAD TAPER – DIN 334. Morse taper shank.
Countersink max Ø
mm
16
20
25 31,5 40
50
63
80
Countersink min Ø
mm 4
5
6,3
10 12,5 16
20
25
Drive
C.M.
1
2
2
2
3
3
4
4
Overall length
mm 90
106 112 118 150 160 190 200
8804G
Each 42,50 59,80 68,30 83,50 132,00 168,00 341,00 592,00
Sizes mm 16 and 20 are running out of stock
vuoto
COUNTERSINKS
8806G
75
HSS
Orig. Dürr - Art. 216-31
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
75° HEAD TAPER. Cylindrical shank.
Countersink max Ø
mm
8
10
12,5
15
20
25
Countersink min Ø
mm 2
2,5
2,8
3,2
3,5
3,8
Drive Ø
mm 6
6
8
8
10
10
Overall length
mm 50
54
54
56
63
71
8806G
Each 25,90 28,50 32,40 43,30 64,30 71,40
vuoto
COUNTERSINKS
8808G
75
HSS
Orig. Dürr - Art. 216-61
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
75° HEAD TAPER. Morse taper shank.
Countersink max Ø
mm
15
20
25
30
Countersink min Ø
mm 3,2
3,5
3,8
4,2
Drive
C.M.
1
1
2
2
Overall length
mm 87
90
110
114
8808G
Each 56,90 65,10 81,60 132,00
Product running out of stock
vuoto
COUNTERSINKS
60°/90° COUNTERSINKS
8809G
60 - 90
HSS
Orig. Dürr - Art. 217-31
Three flutes, HSS ground. For countersinking holes in iron and steel. Vibration-free. 60°/90°
HEAD TAPER. Cylindrical shank.
Countersink max Ø
mm
6
8
10
12
Countersink min Ø
mm 2
2
2
2
Drive Ø
mm 6
8
10
12
Overall length
mm 60
70
75
75
8809G
Each 21,50 22,50 28,10 29,90
Same mills in hardmetal available on request.
vuoto
60°/90°COUNTERSINKS
COUNTERSINKS
8810G
90
HSS
Orig. Dürr - Art. 217-31
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER – DIN 335. Cylindrical shank.
HSS
Countersink max Ø
mm
4,3
5
5,3 5,8
6
6,3
7
7,3
8
8,3 9,4
10 10,4 11,5 12,4
Countersink min Ø
mm 1,3 1,5 1,5 1,5 1,5 1,5 1,8 1,8
2
2
2,2 2,5 2,5 2,8 2,8
Drive Ø
mm 4
4
4
5
5
5
6
6
6
6
6
6
6
8
8
Overall length
mm 40
40
40
45
45
45
50
50
50
50
50
50
50
56
56
8810G
Each 13,30 13,30 14,50 15,10 13,40 13,40 14,50 15,10 14,50 14,80 18,70 17,60 18,10 19,10 19,10
Countersink max Ø
mm
13,4 14,4 15 16,5 19 20,5 23
25
26
28
30
31
40
Countersink min Ø
mm 2,9
2
3,2 3,2 3,5 3,5 3,8 3,8 3,8
4
4,2 4,2
10
Drive Ø
mm 8
8
10
10
10
10
10
10
10
12
12
12
12
Overall length
mm 56
60
60
60
63
63
67
67
67
71
71
71
75
8810G
Each 21,60 24,70 22,20 23,50 32,90 32,90 43,10 45,20 69,80 69,40 70,70 67,80 117,00
vuoto
COUNTERSINKS
