1185 / 1410
1185
Prices in EURO - VAT not included
1185
TUNGSTEN CARBIDE SOLID END MILLS WITH FIRE COATING
13
8799EP
HARTMETALL
FIRE
Orig. Hartner - Art. 84908
Type for high performance of fine-material hardness up to 50 HRC. With special FIRE coating. For
the accentuated spiral angle, for the special processing of the cutting edges and corners of the
cutting edges allows a perfect stability of cut, a feed more fluid and fast, a machining precision
and surface quality at the highest levels.
Long series with standard factory. Type NH with helical multi-cutting edges to 45 °. Cutting right.
Cylindrical shank DIN 6535 HA.
Ø
mm
3
4
5
6
8
10 12 16 20
Overall length
mm 57 57 57 57 63 72 83 92 104
Cutting edge length
mm 8
11 13 13 19 22 26 32 38
Drive Ø
mm 6
6
6
6
8
10 12 16 20
8799EP
Each 35,80 33,80 31,90 31,90 39,10 59,70 82,20 148,00 206,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITH FIRECOATING
8799ER
HARTMETALL
FIRE
Orig. Hartner - Art. 84910
Product description as Art. 8799EP
Extra-long series with standard factory. Type NH with helical multi-cutting edges to 45 °. Cutting
right.
Cylindrical shank DIN 6535 HA.
Ø
mm
6
8
10
12
16
20
Overall length
mm 75
100
100
150
150
150
Cutting edge length
mm 30
40
40
45
65
65
Drive Ø
mm 6
8
10
12
16
20
8799ER
Each 55,10 63,60 114,00 157,00 283,00 424,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITH FIRECOATING
8799ES
HARTMETALL
FIRE
Orig. Hartner - Art. 84907
For high performance roughing with material with hardness up to 54 HRC. With special FIRE
coating. With fine pitch chip breaker, with high surface hardness that allows use also with
compressed air.
Long series DIN 6527 L. Type HR with 4 helical cutting edges to 20°. Cutting right. Front tooth in
the middle.
Cylindrical shank DIN 6535 HB.
Ø
mm
6
8
10
12
16
20
Overall length
mm 57
63
72
83
92
104
Cutting edge length
mm 13
19
22
26
32
38
Drive Ø
mm 6
8
10
12
16
20
8799ES
Each 101,00 109,00 120,00 140,00 223,00 336,00
vuoto
TUNGSTENCARBIDESOLIDENDMILLSWITH FIRECOATING
COUNTERSINKS
8799G
30
HSS
Orig. Dürr - Art. 216-31
Three flutes, HSS ground. For countersinking holes in iron and steel. Vibration-free. 30° HEAD
TAPER. Cylindrical shank.
Countersink max Ø
mm
6,3
12,4
16,5
20,5
25
31
Countersink min Ø
mm 2
3
4
5
6
9
Drive Ø
mm 5
8
10
10
10
12
Overall length
mm 50
65
76
83
90
98
8799G
Each 43,50 64,10 78,10 116,00 149,00 215,00
vuoto
COUNTERSINKS
8799GE
45
HSS
With 3 cutting edges, ground High-Speed Steel. To countersink holes in iron and steel. No
vibrations. 45 ° CONICAL HEAD Cylindrical connection.
Countersink max Ø
mm
12,4
16,5
20,5
25
Countersink min Ø
mm 3
4
5
6
Drive Ø
mm 8
10
10
10
Overall length
mm 64
68
74
78
8799GE
Each 90,90 111,00 159,00 205,00
vuoto
COUNTERSINKS
8800G
60
HSS
Orig. Dürr - Art. 216 -31
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
60° HEAD TAPER – DIN 334. Cylindrical shank.
HSS
Type
6,3
8
10
12,5 12,5L 16
16L
Countersink max Ø
mm 6,3
8
10
12,5
12,5
16
16
Countersink min Ø
mm 1,6
2
2,5
3,2
3,2
4
4
Drive Ø
mm 5
6
6
8
8
10
10
Overall length
mm 45
50
50
56
159
63
162
8800G
Each 14,20 14,50 18,20 19,50 145,00 23,60 182,00
Type
20
20L
25
25L
30
30L 31,5L
Countersink max Ø
mm 20
20
25
25
30
30
31,5
Countersink min Ø
mm 5
5
6,3
6.3
10
4
4
Drive Ø
mm 10
10
10
10
12
12
12
Overall length
mm 67
165
71
169
75
200
200
8800G
Each 33,30 253,00 45,50 298,00 90,90 436,00 412,00
vuoto
COUNTERSINKS
