1188 / 1410
1188
Prices in EURO - VAT not included
1188
COUNTERSINKS
13
8816GE
90
HARTMETALL
Orig. Dürr - Art. 217-23
With ground flutes.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER - DIN 335. Cylindrical shank.
HARDMETAL. For very high resistance steel and materials, such as TITANIUM and its alloys,
manganese, hardened steel up to 60 HRC, INCONEL and similar materials.
Countersink max Ø
mm
10,4
12,4
16,5
20,5
25
31
Countersink min Ø
mm 4
4
4,5
5
5,5
6
Drive Ø
mm 8
8
10
10
10
12
Overall length
mm 46
56
60
63
67
71
Cutting edges
Nr
4
5
5
5
5
5
8816GE
Each 326,00 338,00 408,00 473,00 560,00 740,00
vuoto
COUNTERSINKS
8817G
90
HSS
Orig. Dürr - Art. 217-31
Three flutes, HSS ground.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER. Long and very long cylindrical shank.
Type
5.8
6.3 6.3L 8.3 8.3L 9.4 10.4 10.4L
Countersink max Ø
mm 5,8
6,3
6,3
8,3
8,3
9,4 10,4 10,4
Countersink min Ø
mm 1,5
1,5
1,5
2
2
2,2
2,5
2,5
Drive Ø
mm 5
5
5
6
6
6
6
6
Overall length
mm 104 104 154 105 155 106 107 157
8817G
Each 47,80 42,70 52,30 44,60 54,30 56,10 48,60 60,10
Type
11.5 12.4 12.4L 12.4XL 15 15L 16.5 16.5L
Countersink max Ø
mm 11,5 12,4 12,4 12,4 15
15 16,5 16,5
Countersink min Ø
mm 2,8
2,8
2,8
2,8
3,2
3,2
3,2
3,2
Drive Ø
mm 6
8
8
8
10
10
10
10
Overall length
mm 108 108 158 258 109 159 111 161
8817G
Each 56,10 50,40 66,10 139,00 68,60 89,20 62,10 81,40
Type
16.5XL 20.5 20.5L 20.5XL 25 25L 31 31L
Countersink max Ø
mm 16,5 20,5 20,5 20,5 25
25
31
31
Countersink min Ø
mm 3,2
3,5
3,5
3,5
3,8
3,8
4,2
4,2
Drive Ø
mm 10
10
10
10
10
10
12
12
Overall length
mm 261 114 164 264 118 168 140 190
8817G
Each 182,00 87,20 113,00 252,00 121,00 155,00 206,00 268,00
vuoto
COUNTERSINKS
8818G
90
HSS
Orig. Dürr - Art. 217-91
90° three flutes. HSS.
For countersinking holes in steel and iron. With bicomponent handgrip.
Countersink max Ø
mm
11,5 12,4 15 16,5 19 20,5 23
25
Overall length
mm 125 125 130 130 135 135 140 140
8818G
Each 33,30 33,30 36,40 37,60 47,10 47,10 57,20 59,30
vuoto
COUNTERSINKS
8819G
90
HSS
1/4 ,,
Orig. Völkel - Art. 673
Three flutes, ground. For countersinking holes in iron and steel. 90° HEAD TAPER. HSS steel. 1/
4 – C6.3 hexagonal shank. Suitable for bits handles or battery screwdrivers.
Countersink max Ø
mm
6,3
8,3
10,4
12,4
16,5
20,5
Overall length
mm 31
31
34
35
40
41
8819G
Each 11,60 11,60 12,40 13,10 15,10 16,40
vuoto
COUNTERSINKS
8819GE
90
HSS
1/4 ,,
Prod. SCU
With 3 cutting edges, ground. To countersink holes in iron, steel, light alloys and non-ferrous
alloys. 90° CONICAL HEAD Made of High-Speed Steel. 1/4 hex shank. Suitable for use with
electric and battery screwdrivers.
Countersink max Ø
mm
6,3
8,3
10,4
12,4
16,5
20,5
Overall length
mm 38
38
41
42
47
48
8819GE
Each 10,40 10,40 11,30 13,10 17,60 16,60
vuoto
COUNTERSINKS
8819GF
TIN
90
HSS
1/4 ,,
With 3 cutting edges, ground. To countersink holes in iron, steel, light alloys and non-ferrous
alloys. 90° CONICAL HEAD Made of High-Speed Steel 1/4 hex shank. Suitable for use with
electric and battery screwdrivers.
Countersink max Ø
mm
6,3
8,3
10,4
12,4
16,5
20,5
Overall length
mm 38
38
41
42
47
48
8819GF
Each 16,90 16,90 19,20 24,90 27,70 37,10
vuoto
