1189 / 1410
1189
Prices in EURO - VAT not included
1189
COUNTERSINKS
13
8820G
90
HSS
Orig. Dürr - Art. 217-61
Three flutes, ground.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER – DIN 335. Morse taper shank.
HSS
Countersink max Ø
mm
15 16,5 19 20,5 25
30
31
Countersink min Ø
mm 3,2
3,2
3,5
3,5
3,8
4,2
4,2
Drive
C.M.
1
1
2
2
2
2
2
Overall length
mm 85
85
100 100 106 112 112
8820G
Each 47,70 59,70 60,90 69,80 70,10 78,60 75,50
Countersink max Ø
mm
34
37
40
50
63
80
100
Countersink min Ø
mm 4,5
4,8
10
14
16
22
28
Drive
C.M.
2
2
3
3
4
4
4
Overall length
mm 118 118 140 150 180 190 200
8820G
Each 86,30 89,40 114,00 141,00 233,00 392,00 897,00
Sizes mm 15 and 19 are running out of stock
COUNTERSINKS
8822G
90
HSS
TIN
Three flutes, ground.
For countersinking holes. Vibration-free.
90° HEAD TAPER – DIN 335. Morse taper shank.
HSS, TIN coated.
Countersink max Ø
mm
16,5 20,5 30
31
34
37
40
50
Countersink min Ø
mm 3,2
3,5
4,2
4,2
4,5
4,8
10
14
Drive
C.M.
1
2
2
2
2
2
3
3
Overall length
mm 85
100 112 112 118 118 140 150
8822G
Each 78,90 96,80 139,00 130,00 223,00 230,00 270,00 289,00
Sizes mm 16,5 and 20,5 are running out of stock
COUNTERSINKS
8822GL
90
HSS-E
Three flutes, ground.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER – DIN 335. Morse taper shank.
In COBALT HSS-E.
Countersink max Ø
mm
31
37
40
50
63
80
Countersink min Ø
mm 4,2
4,8
10
14
16
22
Drive
C.M.
2
2
3
3
4
4
Overall length
mm 112 118 140 150 180 190
8822GL
Each 150,00 178,00 222,00 276,00 449,00 763,00
COUNTERSINKS
8823G
90
HSS-E
Orig. Dürr - Art. 217-51
With 5 ground flutes.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER - DIN 335. Morse taper shank.
COBALT HSS-E. For very high resistance steel, such as TITANIUM and its alloys, INCONEL and
similar materials.
Countersink max Ø
mm
31
40
50
63
Countersink min Ø
mm 6
10
14
16
Drive
C.M.
2
3
3
4
Overall length
mm 111
140
150
180
8823G
Each 406,00 503,00 651,00 849,00
COUNTERSINKS
8824G
90
HARTMETALL
Orig. Dürr - Art. 217-53
Three flutes, ground.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER – DIN 335. Morse taper shank.
CARBIDE-TIPPED flutes. For steel and materials difficult to chip,cast iron, aluminium-silicium
alloys and stainless steel.
Countersink max Ø
mm
20,5 25
31
37
40
50
63
80
Countersink min Ø
mm 7
9
10
12
14
18
22
28
Drive
C.M.
2
2
2
2
3
3
4
4
Overall length
mm 100 103 108 115 137 147 179 187
8824G
Each 262,00 322,00 346,00 399,00 447,00 570,00 641,00 831,00
Sizes mm 20,5 - 37 - 63 and 80 are running out of stock
COUNTERSINKS
8824GE
90
HARTMETALL
Orig. Dürr - Art. 217-63
With 5 ground flutes.
For countersinking holes in iron and steel. Vibration-free.
90° HEAD TAPER - DIN 335. Morse taper shank.
HARDMETAL flutes (size 31mm only, with hard metal head). For very high resistant steel and
materials, such as TITANIUM and its alloys, manganese, hardened steel up to 60 HRC, INCONEL
and similar materials.
Countersink max Ø
mm
31
40
50
63
Countersink min Ø
mm 6
14
18
22
Drive
C.M.
2
3
3
4
Overall length
mm 108 137 147 179
8824GE
Each 790,00 826,00 1.070,00 1.340,00
COUNTERSINKS
