1172 / 1410
1172
Prices in EURO - VAT not included
1172
SHELL-END MILLS
13
8756
HSS-E-8%
Spiral flute end mills. Short series. DIN 845 B - UNI 8250 - ISO 1641/2.
Morse taper shank and threaded hole. Cutting tolerance J14.
Ø 12 to 22mm = 4 flute/Ø 24 and 25mm = 5 flute/Ø 30 and 32mm = 6 flute
HSS-E COBALT 8%
Ø
mm
14
15
16
18
20
22
24
Overall length
mm 117
117
117
117
123
140
147
Cutting edge length
mm 32
32
32
32
38
38
45
Drive
C.M.
2
2
2
2
2
3
3
8756
Each 59,80 59,80 59,80 62,20 75,60 96,30 107,00
Ø
mm
25
30
32
Overall length
mm 147
147
178
Cutting edge length
mm 45
45
53
Drive
C.M.
3
3
4
8756
Each 108,00 144,00 177,00
Size Ø 32mm has no cutting edge in the middle.
vuoto
SHELL-ENDMILLS
8757
HSS-E-5%
Spiral flute end mills. Long series. DIN 845 B - UNI 8250 - ISO 1641/2.
Morse taper shank and threaded hole. Cutting tolerance J14.
Ø 12 to 22mm = 4 flute/Ø 24 and 25mm = 5 flute/Ø 30 and 32mm = 6 flute
HSS-E COBALT 5%
Ø
mm
15
16
18
20
22
24
25
Overall length
mm 138
148
148
177
177
192
192
Cutting edge length
mm 53
63
63
75
75
90
90
Drive
C.M.
2
2
2
3
3
3
3
8757
Each 74,40 75,60 78,10 104,00 113,00 119,00 119,00
Ø
mm
30
32
Overall length
mm 192
231
Cutting edge length
mm 90
106
Drive
C.M.
3
4
8757
Each 155,00 205,00
Size Ø 32mm has no cutting edge in the middle.
vuoto
SHELL-ENDMILLS
SINUSOIDAL END MILLS
8758A
HSS-E-8%
Prod. SCU
Sinusoidal flute end mills. Very high performance, vibration reduction, better chip ejection, less
absorbed power, lower sound level, excellent finishing of the processed surface, longer life, higher
speed and feed rates. Short series. Weldon shank. Cutting tolerance J14.
Ø 12mm=3 flute/Ø 16 and 20mm=4 flute/Ø 25mm= 5 flute/Ø 30mm=6 flute
HSS-E COBALT 8%
Ø
mm
12
16
20
25
30
Overall length
mm 83
92
104
121
121
Cutting edge length
mm 26
32
38
45
45
Drive Ø
mm 12
16
20
25
25
8758A
Each 50,10 74,40 104,00 150,00 213,00
vuoto
SINUSOIDALENDMILLS
8758E
HSS-E-8%
TiAIN
Product description as Art. 8758A
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
12
16
20
25
30
Overall length
mm 83
92
104
121
121
Cutting edge length
mm 26
32
38
45
45
Drive Ø
mm 12
16
20
25
25
8758E
Each 74,40 108,00 152,00 224,00 311,00
vuoto
SINUSOIDALENDMILLS
8758F
HSS-E-8%
Sinusoidal flute end mills. Very high performance, vibration reduction, better chip ejection, less
absorbed power, lower sound level, excellent finishing of the processed surface, longer life, higher
speed and feed rates. Long series. Weldon shank. Cutting tolerance J14.
Ø 12mm=3 flute/Ø 16 and 20mm=4 flute/Ø 25mm= 5 flute/Ø 30mm=6 flute
HSS-E COBALT 8%
Ø
mm
12
16
20
25
30
Overall length
mm 110
123
141
166
166
Cutting edge length
mm 53
63
75
90
90
Drive Ø
mm 12
16
20
25
25
8758F
Each 70,70 103,00 144,00 213,00 295,00
vuoto
SINUSOIDALENDMILLS
